Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 200mm -
Travel Rear 203mm -
Fork Öhlins
-
Groupset GX, X01 -
Suspension Full -
Drivetrain 1 × 7 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Aluminum
Suspension Fork
Öhlins DH, 29", Boost
Rear Shock
Öhlins TTX22 Coil
Drivetrain
Rear Derailleur
SRAM GX DH, 7-speed
Front Derailleur
N/A
Shift Levers
SRAM X01 DH, 7-speed
Cassette
SRAM PG720 DH, 11-25 tooth, 7-speed
Crank
Canfield, 165mm
Bottom Bracket
83mm, BSA threaded
Chain Guide
MRP G4 Alloy, 32-36 tooth
Pedals
None
Wheels
Front Hub
Front: Spank Vibrocore 350 wheelset, Rear: Spank Vibrocore 359 wheelset
Rear Hub
Front: Spank Vibrocore 350 wheelset, Rear: Spank Vibrocore 359 wheelset
Rims
Front: Spank Vibrocore 350 wheelset, Rear: Spank Vibrocore 359 wheelset
Spokes
Front: Spank Vibrocore 350 wheelset, Rear: Spank Vibrocore 359 wheelset
Tires
Maxxis Assegai 29" x 2.5" WT
Brakes
Brakes
SRAM Code R, SRAM Centerline 200mm rotors
Brake Levers
SRAM Code R
Cockpit
Stem
Spank, direct mount, 40mm, limited edition
Handlebar
Spank Spike Vibrocore, 800mm, 15mm rise, orange, white, or yellow
Grips
Spank Spike, 30mm
Headset
49.6mm
Seat
Saddle
SDG Radar MTN, custom for Canfield
Seatpost
Spank Custom
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | Size 1 | Size 2 | Size 3 |
|---|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.39 mm | 1.34 mm |
| Bottom Bracket Height | 335 mm | 335 mm | 335 mm |
| Stack | 625 mm | 634 mm | 643 mm |
| Reach | 430 mm | 455 mm | 480 mm |
| Top Tube Length | 577 mm | 605 mm | 634 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 405 mm | 415 mm | 425 mm |
| Head Tube Angle | 63 ° | 63 ° | 63 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1236 mm | 1265 mm | 1295 mm |
| Bottom Bracket Drop | 39 mm | 39 mm | 39 mm |
| Standover Height | 686 mm | 694 mm | 703 mm |
| Wheels | 29" | 29" | 29" |
About this model
ONE.2 is part of the Canfield One2 model. Canfield released 1 bike variation of this model so far.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Average price for Downhill bikes
According to our calculations, the average cost of a Downhill bike that is reliable is 3391$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Downhill bike. To sum up, when you purchase your bike, make sure to check if it has reviews, and also do some components research.
Furthermore, if we have a quick look at this model’s cost, we can see that at its release date the price was 5299$. Comparing this to the average Downhill bike price, we see that the price is 56.27% higher.
ONE.2 components
Fork
The ONE.2 comes factory-installed with the Öhlins fork. This has a travel range of 200mm. Bike forks absorb the shocks and give you a smooth and pleasant ride. To sum up, when buying a bicycle, make sure you get a fork that is capable of delivering decent travel.
Rear Shock
From the factory, it comes with the Öhlins TTX22 Coil rear shock model, which has a travel of 203mm. Rear shocks give you increased comfort, control, and traction, which is important when cornering or braking. This allows you to ride faster on bumpy roads. To sum up, get a full-suspension bike if you want the smoothest rides.
Wheels size
The wheels on ONE.2 are the 29″ aluminum type. Having 29″ wheels means that you need less fork travel, leading to a reduction of the pedal bob effect. However, if you’re not a tall person, you might find it difficult to adapt to this wheel size.
Brakes
Nothing is more important on a bike than its ability to brake properly. Canfield ONE.2 is equipped with Hydraulic Disc brakes. Hydraulic disc brakes provide amazing stopping power, no matter what the terrain. To sum up, you can ride your bike with confidence.
