Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 203mm -
Travel Rear 203mm -
Fork RockShox BoXXer Ultimate
-
Groupset GX, X01 -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
RockShox BoXXer Ultimate 35mm (red)
Rear Shock
RockShox Super D Coil
Drivetrain
Rear Derailleur
SRAM GX DH
Shift Levers
SRAM X01 DH
Cassette
e*thirteen DH7
Crank
Canfield DH
Wheels
Rims
e*thirteen LG1+ DH
Tires
Maxxis Minion DHF 2.5 / Assegai 2.5
Brakes
Brakes
TRP DH-R EVO
Cockpit
Stem
Canfield Special Blend DH 45mm
Handlebar
E.Thirteen Base 800mm
Seat
Saddle
Canfield SDG
Seatpost
RaceFace Chester
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.398 mm | 1.343 mm |
| Bottom Bracket Height | 356.5 mm | 356.5 mm |
| Front Center | 821 mm | 851 mm |
| Rake | 55 mm | 55 mm |
| Trail | 129 mm | 129 mm |
| Stack | 629 mm | 638 mm |
| Reach | 450 mm | 475 mm |
| Top Tube Length | 600 mm | 629 mm |
| Seat Tube Angle | 76 ° | 76 ° |
| Seat Tube Length | 415 mm | 425 mm |
| Head Tube Angle | 63 ° | 63 ° |
| Head Tube Length | 115 mm | 125 mm |
| Chainstay Length | 440 mm | 440 mm |
| Wheelbase | 1260 mm | 1290 mm |
| Bottom Bracket Drop | 22 mm | 22 mm |
| Standover Height | 689 mm | 698 mm |
| Wheels | 29" | 29" |
