Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 203mm -
Travel Rear 203mm -
Fork RockShox BoXXer Ultimate
-
Groupset X01 -
Suspension Full -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
RockShox BoXXer Ultimate 35mm (red)
Rear Shock
Öhlins TTX22m.2
Drivetrain
Rear Derailleur
SRAM X01 DH
Shift Levers
SRAM X01 DH
Cassette
e*thirteen DH7
Crank
Canfield DH
Wheels
Rims
e*thirteen LG1+ DH
Tires
Maxxis Minion DHF 2.5 / Assegai 2.5
Brakes
Brakes
TRP DH-R EVO
Cockpit
Stem
Canfield Special Blend DH 45mm
Handlebar
E.Thirteen Base 800mm
Seat
Saddle
Canfield SDG
Seatpost
RaceFace Chester
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG |
|---|---|---|
| Stack Reach Ratio | 1.398 mm | 1.343 mm |
| Bottom Bracket Height | 356.5 mm | 356.5 mm |
| Front Center | 821 mm | 851 mm |
| Rake | 55 mm | 55 mm |
| Trail | 129 mm | 129 mm |
| Stack | 629 mm | 638 mm |
| Reach | 450 mm | 475 mm |
| Top Tube Length | 600 mm | 629 mm |
| Seat Tube Angle | 76 ° | 76 ° |
| Seat Tube Length | 415 mm | 425 mm |
| Head Tube Angle | 63 ° | 63 ° |
| Head Tube Length | 115 mm | 125 mm |
| Chainstay Length | 440 mm | 440 mm |
| Wheelbase | 1260 mm | 1290 mm |
| Bottom Bracket Drop | 22 mm | 22 mm |
| Standover Height | 689 mm | 698 mm |
| Wheels | 29" | 29" |
