Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 138mm -
Fork Fox Factory Float 34
-
Groupset GX, SRAM -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Fox 34 FLOAT Factory 140mm
Rear Shock
Cane Creek DB Kitsuma AIR
Drivetrain
Rear Derailleur
SRAM GX
Shift Levers
SRAM
Cassette
e*thirteen Helix-R 9-50t
Crank
Canfield AM
Wheels
Rims
e*thirteen LG1+ Enduro
Tires
Maxxis DHF 2.5, Maxxis Dissector 2.4
Brakes
Brakes
TRP Slate T4
Cockpit
Stem
Canfield
Handlebar
e*thirteen Base 800mm
Seat
Seatpost
SDG Tellis
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.447 mm | 1.378 mm | 1.314 mm | 1.258 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm | 343 mm |
| Front Center | 746 mm | 773 mm | 800 mm | 827 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 125 mm | 125 mm | 125 mm | 125 mm |
| Stack | 615 mm | 620 mm | 624 mm | 629 mm |
| Reach | 425 mm | 450 mm | 475 mm | 500 mm |
| Top Tube Length | 566 mm | 593 mm | 620 mm | 646 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 490 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1170 mm | 1198 mm | 1225 mm | 1252 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Standover Height | 697 mm | 730 mm | 762 mm | 779 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
