Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 138mm -
Fork Fox Factory Float 36
-
Groupset X01 -
Suspension Full -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Fox 36 FLOAT Factory 150mm
Rear Shock
Fox FLOAT X Factory
Drivetrain
Rear Derailleur
SRAM XO1
Shift Levers
SRAM XO1
Cassette
SRAM XO1 10-52t
Crank
Canfield AM
Wheels
Rims
Atomik AL 30
Tires
Maxxis DHF 2.5, Maxxis Dissector 2.4
Brakes
Brakes
TRP Trail EVO
Cockpit
Stem
Canfield
Handlebar
e*thirteen Base 800mm
Seat
Seatpost
SDG Tellis
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.447 mm | 1.378 mm | 1.314 mm | 1.258 mm |
| Bottom Bracket Height | 343 mm | 343 mm | 343 mm | 343 mm |
| Front Center | 746 mm | 773 mm | 800 mm | 827 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 125 mm | 125 mm | 125 mm | 125 mm |
| Stack | 615 mm | 620 mm | 624 mm | 629 mm |
| Reach | 425 mm | 450 mm | 475 mm | 500 mm |
| Top Tube Length | 566 mm | 593 mm | 620 mm | 646 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 490 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 110 mm | 115 mm | 120 mm | 125 mm |
| Chainstay Length | 425 mm | 425 mm | 425 mm | 425 mm |
| Wheelbase | 1170 mm | 1198 mm | 1225 mm | 1252 mm |
| Bottom Bracket Drop | 32 mm | 32 mm | 32 mm | 32 mm |
| Standover Height | 697 mm | 730 mm | 762 mm | 779 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
