Canfield YELLI SCREAMY CORE 2024
2024 Mountain
Estimate price |
4,749$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 130mm -
Fork Cane Creek HELM
-
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
157cm - 170cm
MD
165cm - 180cm
LG
175cm - 190cm
XL
185cm - 198cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Suspension Fork
Cane Creek Helm 130mm
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM GX Eagle
Cassette
e*thirteen Helix-R 9-50t
Crank
Canfield AM
Wheels
Rims
E.Thirteen
Tires
Maxxis Minion DHF 2.5 / Maxxis Dissector 2.4
Brakes
Brakes
TRP Slate T4
Cockpit
Stem
Canfield Special Blend 40mm
Handlebar
e*thirteen 800mm
Grips
Lizard Skins Charger Evo
Seat
Seatpost
SDG Tellis
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.482 mm | 1.411 mm | 1.356 mm | 1.298 mm |
| Bottom Bracket Height | 316.5 mm | 316.5 mm | 316.5 mm | 316.5 mm |
| Front Center | 736 mm | 763 mm | 793 mm | 820 mm |
| Rake | 44 mm | 44 mm | 44 mm | 43 mm |
| Trail | 122 mm | 122 mm | 122 mm | 123 mm |
| Stack | 630 mm | 635 mm | 644 mm | 649 mm |
| Reach | 425 mm | 450 mm | 475 mm | 500 mm |
| Top Tube Length | 571 mm | 597 mm | 624 mm | 650 |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° | 77 ° |
| Seat Tube Length | 380 mm | 420 mm | 460 mm | 490 mm |
| Head Tube Angle | 65.5 ° | 65.5 ° | 65.5 ° | 65.5 ° |
| Head Tube Length | 105 mm | 110 mm | 120 mm | 125 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1154 mm | 1181 mm | 1210 mm | 1237 mm |
| Bottom Bracket Drop | 58 mm | 58 mm | 58 mm | 58 mm |
| Standover Height | 677 mm | 709 mm | 746 mm | 769 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 157 cm | 165 cm | 175 cm | 185 cm |
| Rider Max Height | 170 cm | 180 cm | 190 cm | 198 cm |
