Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork Cannondale Lefty Ocho Carbon
-
Groupset XTR, XT -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 159cm
SM
156cm - 165cm
MD
167cm - 175cm
LG
172cm - 182cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
BallisTec Carbon, SAVE, PF30-83, tapered head tube, Speed Release 12mm thru axle, Ai Offset
Suspension Fork
Lefty Ocho Carbon, 100mm, Chamber Damper with remote lockout, OppO Spring System, tapered steerer, 55mm offset (29"), 50mm offset (27.5)
Drivetrain
Rear Derailleur
Shimano XTR
Shift Levers
Shimano XT, 12-speed
Cassette
Shimano XT, 10-51, 12-speed
Crank
HollowGram, BB30a, OPI SpideRing, 34T, Ai offset
Bottom Bracket
Cannondale Alloy PressFit30
Chain
Shimano XT, 12-speed
Pedals
Not included
Wheels
Front Hub
(F) HollowGram Lefty 60 / (R) HollowGram w/DT Swiss Star Ratchet internals, 12x148mm
Rear Hub
(F) HollowGram Lefty 60 / (R) HollowGram w/DT Swiss Star Ratchet internals, 12x148mm
Rims
HollowGram 25, Superlight Hi-Impact Carbon, 28h, 25mm inner width, tubeless ready
Spokes
HollowGram, 2.0/1.8/2.0, straight-pull
Tires
(F) Schwalbe Racing Ray EVO, 29x2.25", SnakeSkin, Addix Speedgrip, tubeless ready, (R) Schwalbe Racing Ralph EVO, 29x2.25", SnakeSkin, Addix Speed, tubeless ready
Brakes
Brakes
Shimano XT hydraulic disc, 160/160mm XT rotors
Brake Levers
Shimano XT hydraulic disc
Cockpit
Stem
Cannondale 2, 6061 Alloy, 31.8, 7°
Handlebar
Cannondale 1 Flat, Carbon, 31.8mm, 9° backsweep, 760mm
Grips
ESI Chunky Silicone, 32mm dia.
Headset
Integrated, 1-1/8 to 1.5", sealed angular contact bearings (Integrated steer stop size small only)
Seat
Saddle
Prologo Dimension NDR, Tirox rails
Seatpost
Cannondale 2, UD Carbon, 27.2x400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 156 cm | 167 cm | 172 cm | 185 cm |
| Rider Max Height | 159 cm | 165 cm | 175 cm | 182 cm | 195 cm |
