Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 27.5" -
Travel Front 140mm -
Travel Rear 130mm -
Fork RockShox Pike
-
Groupset NX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 157cm
SM
154cm - 165cm
MD
162cm - 175cm
LG
172cm - 182cm
XL
180cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Habit SmartForm C1 Alloy, 130mm travel, Proportional Response Suspension and Geo, 55mm chainline, ISCG05, BSA threaded BB, post mount brake, tapered headtube, DirectLine internal cable routing, UDH hanger
Suspension Fork
RockShox Pike, 140mm, DebonAir, 15x110mm thru-axle, tapered steered, 42mm offset
Rear Shock
RockShox Deluxe Select+, DebonAir, 2-Pos mode adjust, adjustable rebound
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM NX Eagle, 12-speed
Cassette
SRAM NX Eagle, 10-50, 12-speed
Crank
SRAM NX Eagle DUB, 30T, 55mm chainline
Bottom Bracket
SRAM DUB BSA MTB73 Wide
Chain
SRAM SX Eagle, 12-speed
Pedals
Not included
Wheels
Front Hub
(F) Shimano MT400, 15x110mm thru-axle / (R) Shimano MT410, 12x148mm thru-axle
Rear Hub
(F) Shimano MT400, 15x110mm thru-axle / (R) Shimano MT410, 12x148mm thru-axle
Rims
Stan's NoTubes Arch D, 32h, tubeless ready
Spokes
Stainless Steel, 14g
Tires
(F) Maxxis Dissector, 29x2.4" (27.5x2.4" - XS) EXO, tubeless ready, (R) Maxxis Rekon, 29x2.4" (27.5x2.4" - XS) EXO, tubeless ready
Brakes
Brakes
SRAM G2 R hydraulic disc, 180/180mm CenterLine rotors
Brake Levers
SRAM G2 R hydraulic disc
Cockpit
Stem
Cannondale 3, 6061 Alloy, 31.8, 0°
Handlebar
Cannondale 3 Riser, 6061 Alloy, 15mm rise, 8° sweep, 4° rise, 780mm
Grips
Cannondale TrailShroom
Headset
Integrated Sealed Bearing, Tapered
Seat
Saddle
Cannondale Scoop Shallow Sport, steel rails
Seatpost
TranzX dropper, internal routing, 31.6, 130mm (XS-S), 150mm (M-XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 27" | 27" | 27" | 27" | 27" |
| Rider Min Height | 152 cm | 154 cm | 162 cm | 172 cm | 180 cm |
| Rider Max Height | 157 cm | 165 cm | 175 cm | 182 cm | 195 cm |
