Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 20" -
Groupset microSHIFT -
Suspension Rigid -
Drivetrain 1 × 7 -
Brakes Rim
Sizing
Recommended size guide.
OS
116cm - 129cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SmartForm C3 Alloy, rim brakes, rack/fender mounts
Suspension Fork
Rigid, SmartForm C3 Alloy, 1" steerer, fender mounts
Drivetrain
Rear Derailleur
microSHIFT M21S
Shift Levers
microSHIFT, low-torque Twist Shift, 7-speed
Cassette
Sunrace, 11-28, 7-speed
Crank
Prowheel, Pro-V30, 110mm length, 30T
Bottom Bracket
Cartridge, square taper
Chain
KMC Z7, 7-speed
Pedals
Wellgo Composite Platform w/ reflectors, 1/2"
Wheels
Front Hub
(F) KT Alloy, QR / (R) KT Alloy, 7-speed freehub
Rear Hub
(F) KT Alloy, QR / (R) KT Alloy, 7-speed freehub
Rims
Cannondale, lightweight alloy, 20", 28h
Spokes
Steel, 14g Black
Tires
Kenda Small Block 8, 20x1.5"
Brakes
Brakes
Promax V-Brake
Brake Levers
Alloy, linear pull
Cockpit
Stem
Forged and machined aluminum, 30mm w/ fitted stem cover
Handlebar
Lightweight Alloy, 25.4mm, 580mm
Grips
Cannondale Kid's Comfort
Headset
FSA, Alloy, 1-1/8" Ahead, semi-integrated
Seat
Saddle
Cannondale Kid's Comfort
Seatpost
One-piece, clamp-less, Alloy, 25.4mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | OS |
|---|---|
| Wheels | 20" |
| Rider Min Height | 116 cm |
| Rider Max Height | 129 cm |
