Cannondale Mavaro 4 2025
2025 E-bike
Estimate price |
4,071$
E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour MOBIE
-
Groupset Nexus -
Suspension Hardtail -
Motor Bosch 600W 50Nm mid-drive -
Battery Bosch PowerTube, 500Wh -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
SM
160cm - 172cm
MD
169cm - 185cm
LG
175cm - 190cm
XL
180cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Mavaro, SmartForm C2 Alloy, removable 500Wh downtube battery, integrated headtube reflector, tapered headtube, internal cable routing, 135mm QR hub spacing, IS disc mount, motor protection
Suspension Fork
SR Suntour Mobie A32, 63mm travel, coil with preload adjuster, lockout, crown light mount, 44mm offset
Drivetrain
Shift Levers
Shimano Nexus Revoshift, 5-speed twist shifter
Cassette
Gates CDC, 34T
Crank
Gates Bosch E-bike, w/ 46T sprocket
Bottom Bracket
Bosch, press-fit
Chain
Gates CDC carbon drive belt
Pedals
Cannondale Fitness
Wheels
Front Hub
(F) Shimano TC500, 15x110mm thru-axle / (R) Shimano Nexus Inter-5E, 5-speed internal gear hub
Rear Hub
(F) Shimano TC500, 15x110mm thru-axle / (R) Shimano Nexus Inter-5E, 5-speed internal gear hub
Rims
Alloy, double wall, 32 hole, 25mm internal width, disc-specific
Spokes
Stainless Steel, 14g
Tires
Continental eContact Plus w/ reflective sidewalls , 29x2.2" 55-622 (M,L,XL), 27.5x2.2" 55-584 (S)
Brakes
Brakes
Shimano MT200 hydraulic disc, 180/160mm RT30 rotors
Brake Levers
Shimano MT200 hydraulic disc
Cockpit
Stem
Cannondale 3 w/ Intellimount, Alloy, 31.8mm clamp, 70mm, +6°, w/ SP Connect SPC+ Stem Mount
Handlebar
Cannondale Urban Ergo Bar, 6061 Alloy, 25mm rise, 35° sweep, 0° rise, 680mm
Grips
Ergon GC10
Headset
Semi-Integrated, Tapered; 1-1/8"-1-1/2"
Seat
Saddle
Selle Royal Nuvola
Seatpost
Cannondale 4, 6061 Alloy, 31.6, 300 (SM), 350mm (MD), 400mm (XL)
Motor & Battery
Motor
Bosch Active Line Plus, Smart System
Battery
Bosch PowerTube, 500Wh
Charger
Bosch 2A
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 160 cm | 169 cm | 175 cm | 180 cm |
| Rider Max Height | 172 cm | 185 cm | 190 cm | 200 cm |
