Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
137cm - 157cm
SM
154cm - 164cm
MD
161cm - 172cm
LG
170cm - 184cm
XL
181cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SmartForm C3 Alloy, SAVE, 1-1/8" headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, BSA-73
Suspension Fork
SR Suntour XCT, 100mm, coil, 42mm offset (27.5") 46mm offset (29")
Drivetrain
Rear Derailleur
Shimano Acera
Front Derailleur
Shimano Altus, 34.9mm clamp
Shift Levers
Shimano M315 Rapidfire Plus, 8-speed
Cassette
Sunrace, 11-34, 8-speed
Crank
Prowheel, 36/22
Bottom Bracket
Sealed cartridge bearing, square taper
Chain
KMC X8, 8-speed
Pedals
Cannondale Platform
Wheels
Front Hub
Shimano QC300, QR
Rear Hub
Shimano QC300, QR
Rims
WTB SX19, 32h
Spokes
Stainless Steel, 14g
Tires
WTB Ranger Comp, 29x2.25" (27.5x2.25" - XS, SM), DNA Compound
Brakes
Brakes
Tektro M275 hydraulic disc, 160/160mm rotors
Brake Levers
Tektro hydraulic disc
Cockpit
Stem
6061 Alloy, 31.8, 7°
Handlebar
Cannondale Riser, 6061 Alloy, 25mm rise, 8° sweep, 6° rise, 720mm
Grips
Cannondale Dual-Density
Headset
Semi-Integrated, 1-1/8"
Seat
Saddle
Cannondale Stage 3
Seatpost
Cannondale 3, 6061 Alloy, 31.6x350mm (XS - SM), 400mm (MD-XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 137 cm | 154 cm | 161 cm | 170 cm | 181 cm |
| Rider Max Height | 157 cm | 164 cm | 172 cm | 184 cm | 190 cm |
