Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset microSHIFT Acolyte -
Suspension Hardtail -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
137cm - 157cm
SM
154cm - 162cm
MD
160cm - 172cm
LG
170cm - 182cm
XL
180cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
SmartForm C3 Alloy, SAVE, 1-1/8" headtube, post mount disc, StraightShot internal cable routing, dropper post compatible, BSA-73
Suspension Fork
SR Suntour XCT DS, 100mm, coil, 42mm offset (27.5") 46mm offset (29")
Drivetrain
Rear Derailleur
microSHIFT Acolyte
Shift Levers
microSHIFT Acolyte, 8-speed
Cassette
microSHIFT, 12-42, 8-speed cassette
Crank
Prowheel, 30T
Bottom Bracket
Sealed cartridge bearing, square taper
Chain
KMC Z8.1, 8-speed
Pedals
Cannondale Platform
Wheels
Front Hub
(F) Formula DC-1420, QR / (R) Formula DC-1422 HG freehub, QR
Rear Hub
(F) Formula DC-1420, QR / (R) Formula DC-1422 HG freehub, QR
Rims
WTB SX19, 32h
Spokes
Stainless Steel, 14g
Tires
WTB Ranger Comp, 29x2.25" (27.5x2.25" - XS, SM), DNA Compound
Brakes
Brakes
Tektro M275 hydraulic disc, 160/160mm rotors
Brake Levers
Tektro hydraulic disc
Cockpit
Stem
6061 Alloy, 31.8, 8°
Handlebar
6061 Alloy Riser, 31.8mm, 25mm rise, 700mm
Grips
Cannondale Dual-Density
Headset
Semi-Integrated, 1-1/8"
Seat
Saddle
Cannondale Stage 3
Seatpost
Cannondale 3, 6061 Alloy, 31.6x350mm (XS - SM), 400mm (MD-XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Min Height | 137 cm | 154 cm | 160 cm | 170 cm | 180 cm |
| Rider Max Height | 157 cm | 162 cm | 172 cm | 182 cm | 190 cm |
