Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 120mm -
Fork RockShox 35 Gold RL
-
Groupset NX Eagle, SX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
154cm - 164cm
MD
161cm - 172cm
LG
170cm - 184cm
XL
181cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Smartform C2 Alloy, SAVE dropped seatstays, tapered headtube, post mount disc, StraightShot internal cable routing, dropper post compatible BSA 73, 12mm thru axle, Boost 148
Suspension Fork
RockShox 35 Gold RL, 120mm, Debonair, 15x110 thru-axle, 51mm offset
Drivetrain
Rear Derailleur
SRAM NX Eagle
Shift Levers
SRAM SX Eagle, 12-speed
Cassette
SRAM SX Eagle, 11-50, 12-speed
Crank
SRAM SX Eagle Power Spline, 30T
Bottom Bracket
Truvativ Power Spline
Chain
SRAM NX Eagle, 12-speed
Pedals
Cannondale Platform
Wheels
Front Hub
Shimano TC500, 15x110mm thru-axle
Rear Hub
Shimano TC500 , 12x148mm thru-axle
Rims
WTB ST i29 TCS, 32h, tubeless ready
Spokes
Stainless Steel, 14g
Tires
(F) Maxxis Minion DHF, 29x2.5” Exo Casing, Tubeless Ready / (R) Maxxis High Roller II, 29x2.3", EXO casing, tubeless ready
Brakes
Brakes
TRP Slate G4 4-piston hydraulic disc, 180/160mm rotors
Brake Levers
TRP Slate hydraulic disc
Cockpit
Stem
Cannondale 3, 6061 Alloy, 31.8, 0°
Handlebar
FSA Alloy Riser, 15mm rise, 760mm
Grips
Fabric FunGuy
Headset
Integrated Sealed Bearing, Tapered
Seat
Saddle
Cannondale Ergo XC
Seatpost
Dropper post, 31.6, Internal Routing, 80mm (S), 130mm (M-XL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 154 cm | 161 cm | 170 cm | 181 cm |
| Rider Max Height | 164 cm | 172 cm | 184 cm | 190 cm |
