Canyon Neuron CF 8 WMN 2024
2024 Mountain
Estimate price |
3,489$
Weight | 13.28 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 140mm -
Fork Fox Performance Float 34
-
Groupset SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
165cm - 176cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Neuron, Superlight carbon full-suspension MTB frame featuring a balanced geometry which combines trail capability with all-day comfort., Axle dimension: 12x148 mm, Material: Carbon (CF)
Suspension Fork
FOX 34 Float Performance GRIP, Axle dimension: 15x110 mm, Stanchion Diameter: 34 mm, Travel: 140 mm, Fork steer tube diameter: 1 1/8" - 1,5", Offset: 44 mm
Rear Shock
FOX Float DPS Performance
Drivetrain
Rear Derailleur
Shimano SLX M7100, Cage length: long, Weight: 286 g
Shift Levers
Shimano SLX M7100, Weight: 143 g
Cassette
Shimano SLX M7100, Number of sprockets: 12, Range: 10-51 12S
Crank
Shimano SLX M7120, Number of chainrings: 1
Bottom Bracket
Shimano BSA BB52, Bottom bracket standard: BSA HT2 68/73, Weight: 98 g
Chain
Shimano CN-M6100
Chain Guide
Canyon EP1538-01 Chain Guide
Pedals
None included
Wheels
Rims
DT Swiss XM 1700, Axle dimension: 15x110 mm, Rotor mount: Center Lock, Rim height: 21 mm, Inner width: 30 mm, Weight: 10 g | DT Swiss XM 1700, Axle dimension: 12x148 mm, Rotor mount: Center Lock, Rim height: 21 mm, Inner width: 30 mm, Weight: 10 g
Tires
Schwalbe Nobby Nic 29x2.4 black skin, Width: 2.4" | Schwalbe Wicked Will 29"x2.4", Width: 2.4"
Brakes
Brakes
Shimano SLX M7120
Cockpit
Stem
Race Face Ride, Fork steer tube diameter: 1 1/8", Clamping diameter: 35,0 mm
Handlebar
Race Face Ride Riserbar, Clamping diameter: 35,0 mm, Width: 740 mm, Rise: 10 mm
Grips
Ergon GA20
Seat
Saddle
Ergon SM10 Sport Women, Weight: 290 g
Seatpost
Canyon G5, Clamp diameter: 30,9 mm, Material: Aluminium (AL)
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD |
|---|---|---|---|
| Stack Reach Ratio | 1.386 mm | 1.386 mm | 1.376 mm |
| Bottom Bracket Height | 337 mm | 337 mm | 336 mm |
| Front Center | 735 mm | 735 mm | 766 mm |
| Rake | 43 mm | 43 mm | 44 mm |
| Trail | 111 mm | 111 mm | 119 mm |
| Stack | 596 mm | 596 mm | 626 mm |
| Reach | 430 mm | 430 mm | 455 mm |
| Top Tube Length | 579 mm | 579 mm | 611 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 390 mm | 390 mm | 425 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° |
| Head Tube Length | 100 mm | 100 mm | 110 mm |
| Chainstay Length | 430 mm | 430 mm | 440 mm |
| Wheelbase | 1164 mm | 1164 mm | 1203 mm |
| Bottom Bracket Drop | 18 mm | 18 mm | 38 mm |
| Standover Height | 756 mm | 759 mm | 777 mm |
| Front Travel | 140 mm | 140 mm | 140 mm |
| Wheels | 27" | 27" | 29" |
| Rider Max Height | 167 cm | 176 cm | cm |
