Canyon Spectral CLLCTV 2025
2025 Mountain
Estimate price |
4,652$
Weight | 16.04 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 150mm -
Travel Rear 140mm -
Fork RockShox Lyrik Ultimate
-
Groupset Eagle AXS, S1000 Eagle Transmission -
Suspension Full -
Battery SRAM Powerpack -
Drivetrain 1 × 12 Electronic -
Brakes SRAM Maven Silver Hydraulic Disc
Sizing
Recommended size guide.
SM
163cm - 177cm
MD
172cm - 185cm
LG
180cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Spectral, Aluminium frame with optimised frame forms for increased stiffness and strength with thinner walls. Category 4., Material: Aluminium (AL), Weight: 3,130 g
Suspension Fork
RockShox Lyrik Ultimate, Travel: 150 mm, Fork steer tube diameter: 1 1/8" - 1,5", Weight: 2,028 g
Rear Shock
RockShox Super Deluxe Ultimate, Weight: 526 g
Drivetrain
Rear Derailleur
SRAM S1000 Eagle Transmission, Weight: 443 g
Shift Levers
SRAM AXS Pod, Weight: 67 g
Cassette
SRAM XS-1275, Number of sprockets: 12, Range: 10-52
Crank
SRAM S1000
Bottom Bracket
SRAM DUB BSA, Bottom bracket standard: BSA 73, Weight: 78 g
Chain
SRAM GX Eagle Transmission
Pedals
None included
Wheels
Rims
DT Swiss XM1700, Axle dimension: 15x110 mm, Rotor mount: IS 6-bolt, Weight: 920 g | DT Swiss XM1700, Axle dimension: 12x148 mm, Rotor mount: IS 6-bolt, Weight: 1,010 g
Tires
Pirelli Scorpion Race Endruo M, Width: 2.5", Weight: 1,300 g | Pirelli Scorpion Race Enduro T, Width: 2.5", Weight: 1,184 g
Brakes
Brakes
SRAM Maven Silver Stealth, Number of pistons: 4
Cockpit
Stem
Canyon G5, Modern design, extreme durability: Canyon G5 components were developed by our pros on the world's toughest trails., Fork steer tube diameter: 1 1/8", Clamping diameter: 31,8 mm, Material: Aluminium (AL)
Handlebar
Canyon G5, G5 stands for gravity riding, and category 5. This aluminium bar has superb ergonomics and durability., Clamping diameter: 31,8 mm, Width: 780 mm, Rise: 30 mm
Grips
Canyon G5
Seat
Saddle
Ergon SM10 Enduro, Gender: Unisex, Weight: 314 g
Seatpost
Canyon SP0081, Clamp diameter: 34,9 mm, Material: Aluminium (AL), Weight: 700 g
Motor & Battery
Battery
SRAM Powerpack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.44 mm | 1.38 mm | 1.326 mm | 1.278 mm | 1.234 mm |
| Front Center | 757 mm | 786 mm | 816 mm | 845 mm | 874 mm |
| Rake | 45 mm | 45 mm | 46 mm | 45 mm | 45 mm |
| Trail | 133 mm | 133 mm | 131 mm | 133 mm | 133 mm |
| Stack | 612 mm | 621 mm | 630 mm | 639 mm | 648 mm |
| Reach | 425 mm | 450 mm | 475 mm | 500 mm | 525 mm |
| Top Tube Length | 572 mm | 599 mm | 626 mm | 653 mm | 680 mm |
| Seat Tube Angle | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° | 76.5 ° |
| Seat Tube Length | 375 mm | 400 mm | 415 mm | 445 mm | 455 mm |
| Head Tube Angle | 64 ° | 64 ° | 64 ° | 64 ° | 64 ° |
| Head Tube Length | 100 mm | 110 mm | 120 mm | 130 mm | 140 mm |
| Chainstay Length | 437 mm | 437 mm | 437 mm | 437 mm | 437 mm |
| Wheelbase | 1192 mm | 1221 mm | 1251 mm | 1280 mm | 1309 mm |
| Bottom Bracket Drop | 36 mm | 36 mm | 36 mm | 36 mm | 36 mm |
| Standover Height | 744 mm | 749 mm | 757 mm | 761 mm | 762 mm |
| Front Travel | 150 mm | 150 mm | 150 mm | 150 mm | 150 mm |
| Rear Travel | 140 mm | 140 mm | 140 mm | 140 mm | 140 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
| Rider Max Height | 168 cm | 177 cm | 185 cm | 194 cm | cm |
