Canyon Speedmax CF 7 Di2 AR60 2025
2025 Road
Estimate price |
5,799$
Weight | 9.33 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Dura-Ace Di2, 105 Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Shimano Hydraulic Disc
Sizing
Recommended size guide.
MD
173cm - 187cm
LG
185cm - 197cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Speedmax CF Disc, Aero frame shaped by extensive computational fluid dynamics analysis, validated in the wind tunnel with our aero partners Swiss Side. Internal cable routing, 12x142 mm through axle (rear), flat-mount disc standard., Material: Carbon (CF), Weight: 1380 g
Suspension Fork
Canyon Fork FK0120, Fully internal cable routing, radical deep profile design, covered brake calipers for enhanced aerodynamics, 12x100 mm through axle, flat-mount disc standard. CT scanner tested and approved., Axle dimension: 12x100 mm, Fork steer tube diameter: 1 1/8", Tyre clearance: 30 mm, Material: Carbon (CF), Weight: 1.23 lbs
Drivetrain
Rear Derailleur
Shimano 105 Di2 RD, Weight: 0.66 lbs
Front Derailleur
Shimano 105 Di2 FD-R7150, Weight: 0.30 lbs
Shift Levers
Shimano Dura-Ace Di2 R9160 Remote TT, Weight: 0.04 lbs
Cassette
Shimano 105 R7100, 12-speed, 11-34T, Number of sprockets: 12, Range: 11-34
Crank
Shimano 105 R7100, Number of chainrings: 2
Bottom Bracket
Token Ninja Lite BB4124, Bottom bracket standard: PF 86,5, Weight: 0.19 lbs
Chain
Shimano CN-M7100 12s
Pedals
None included
Wheels
Rims
Reynolds AR60, Axle dimension: 12x142 mm, Rotor mount: Center Lock, Rim height: 60 mm, Weight: 1.91 lbs | Reynolds AR60, Axle dimension: 12x100 mm, Rotor mount: Center Lock, Rim height: 60 mm, Rim material: Carbon, Weight: 1.70 lbs
Tires
Continental Grand Prix 5000 S TR, 25mm, Width: 25 mm, Weight: 0.54 lbs | Continental Grand Prix 5000 S TR, 28mm, Width: 28 mm, Weight: 0.65 lbs
Brakes
Brakes
Shimano Flat Mount Adapter +20mm
Brake Levers
Shimano Dura-Ace Di2 ST-R9180, Number of pistons: 2, Weight: 0.58 lbs
Cockpit
Handlebar
Profile Design Extension
Seat
Saddle
Selle Italia Watt Superflow, Gender: Unisex, Max. Rider Weight: 100 kg, Weight: 0.55 lbs
Seatpost
Canyon SP0048 Aero Seatpost, Speedmax time trial seatpost, deep profile, large adjustment range, UCI compliant., Weight: 300 g
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.291 mm | 1.295 mm | 1.305 mm | 1.299 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 264 mm | 264 mm |
| Front Center | 579 mm | 605 mm | 637 mm | 671 mm |
| Rake | 34 mm | 34 mm | 34 mm | 34 mm |
| Trail | 67 mm | 67 mm | 67 mm | 67 mm |
| Stack | 519 mm | 544 mm | 578 mm | 608 mm |
| Reach | 402 mm | 420 mm | 443 mm | 468 mm |
| Top Tube Length | 489 mm | 511 mm | 540 mm | 570 mm |
| Seat Tube Angle | 80.5 ° | 80.5 ° | 80.5 ° | 80.5 ° |
| Seat Tube Length | 518 mm | 543 mm | 577 mm | 607 mm |
| Head Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 115 mm | 140 mm | 176 mm | 207 mm |
| Chainstay Length | 420 mm | 420 mm | 420 mm | 420 mm |
| Wheelbase | 988 mm | 1014 mm | 1047 mm | 1081 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 72 mm | 72 mm |
| Standover Height | 791 mm | 815 mm | 849 mm | 879 mm |
| Wheels | 700 | 700 | 700 | 700 |
| Rider Max Height | 175 cm | 187 cm | 197 cm | cm |
