Canyon Torque 29 AL 5 2024
2024 Mountain
Estimate price |
2,999$
Weight | 16.44 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 170mm -
Travel Rear 170mm -
Fork RockShox ZEB Select
-
Groupset Deore -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
LG
180cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Torque AL, A big send, long-travel aluminium freeride frame with progressive, ultra-capable geometry., Axle dimension: 12x148 mm, Material: Aluminium (AL)
Suspension Fork
ROCKSHOX ZEB SELECT, Axle dimension: 15x110 mm, Stanchion Diameter: 38 mm, Travel: 170 mm, Fork steer tube diameter: 1 1/8" - 1,5", Weight: 5.29 lbs
Rear Shock
RockShox Super Deluxe Select+, Weight: 1.06 lbs
Drivetrain
Rear Derailleur
Shimano Deore M6100, Cage length: long, Weight: 0.70 lbs
Shift Levers
Shimano Deore M6100, Weight: 0.30 lbs
Cassette
Shimano Deore M6100, Number of sprockets: 12
Crank
Shimano Deore FC-M6120-1, Number of chainrings: 1
Bottom Bracket
Shimano BSA BB52, Bottom bracket standard: BSA HT2 68/73, Weight: 0.22 lbs
Chain
Shimano CN-M6100
Chain Guide
Canyon Chainguide
Pedals
None included
Wheels
Rims
RaceFace AR30 | Shimano MT400, Axle dimension: 15x110 mm, Rotor mount: Center Lock, Weight: 2.62 lbs | RaceFace AR30 | Shimano MT510 SH12, Rotor mount: Center Lock, Weight: 2.25 lbs
Tires
Maxxis Minion DHR II 3C MaxxTerra, Width: 2.4" | Maxxis Assegai 3C MaxxGrip, Width: 2,5", Weight: 2.56 lbs
Brakes
Brakes
Shimano Deore M6120 | Shimano Deore
Cockpit
Stem
Canyon G5, Modern design, extreme durability: Canyon G5 components were developed by our pros on the world's toughest trails., Fork steer tube diameter: 1 1/8", Clamping diameter: 31,8 mm, Material: Aluminium (AL)
Handlebar
Canyon G5, G5 stands for gravity riding, and category 5. This aluminium bar has superb ergonomics and durability., Clamping diameter: 31,8 mm, Width: 780 mm, Rise: 30 mm
Grips
Canyon G5
Seat
Saddle
Fizik Gravita Alpaca X5, Gender: Unisex, Weight: 0.49 lbs
Seatpost
Iridium Dropper Post, Move more freely on steep descents, by dropping down saddle with the press of a handlebar-mounted button. With internal cabling., Clamp diameter: 30,9 mm, Material: Aluminium (AL), Weight: 1.28 lbs
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | MD | LG | XL |
|---|---|---|---|
| Stack Reach Ratio | 1.365 mm | 1.313 mm | 1.267 mm |
| Bottom Bracket Height | 344 mm | 344 mm | 344 mm |
| Front Center | 808 mm | 838 mm | 867 mm |
| Rake | 44 mm | 44 mm | 44 mm |
| Trail | 138 mm | 138 mm | 138 mm |
| Stack | 628 mm | 637 mm | 646 mm |
| Reach | 460 mm | 485 mm | 510 mm |
| Top Tube Length | 594 mm | 620 mm | 647 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 430 mm | 435 mm | 475 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1247 mm | 1277 mm | 1306 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm |
| Standover Height | 766 mm | 768 mm | 775 mm |
| Front Travel | 170 mm | 170 mm | 170 mm |
| Rear Travel | 170 mm | 170 mm | 170 mm |
| Wheels | 29" | 29" | 29" |
| Rider Max Height | 185 cm | 194 cm | cm |
