Canyon Torque CF CLLCTV FW 2024
2024 Mountain
Estimate price |
6,307$
Weight | 15.95 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Travel Front 170mm -
Travel Rear 175mm -
Fork Öhlins RXF38
-
Groupset X0, X0 Eagle Transmission -
Suspension Full -
Battery SRAM Powerpack -
Drivetrain 1 × 12 Electronic -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
172cm - 185cm
LG
180cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Torque CF, Axle dimension: 12x148 mm, Material: Carbon (CF)
Suspension Fork
Öhlins RXF38, Axle dimension: 15x110 mm, Stanchion Diameter: 38 mm, Travel: 170 mm, Fork steer tube diameter: 1 1/8" - 1,5", Weight: 2.32 kg
Rear Shock
Öhlins TTX22M, Spring: 388
Drivetrain
Rear Derailleur
SRAM X0 Eagle AXS Transmission, Weight: 34 g
Shift Levers
SRAM Eagle AXS Controller
Cassette
SRAM XS 1275, Number of sprockets: 12, Range: 10-52
Crank
SRAM XO Eagle, Number of chainrings: 1
Bottom Bracket
SRAM DUB BSA, Bottom bracket standard: BSA 73, Weight: 5 g
Chain
SRAM GX Eagle Transmission
Chain Guide
Canyon EP1266-01 ISCG05 Plate | Canyon GP0293-02
Pedals
None included
Wheels
Rims
DT Swiss FR1700, Axle dimension: 15x110 mm, Rotor mount: IS 6-bolt, Weight: 940 g | DT Swiss FR1700, Axle dimension: 12x148 mm, Rotor mount: IS 6-bolt, Weight: 988 g
Tires
Pirelli Scorpion Race Endruo M, Width: 2.5", Weight: 1.30 kg | Pirelli Scorpion Race Enduro T, Width: 2.5"
Brakes
Brakes
Magura MT7
Cockpit
Stem
Canyon G5, Modern design, extreme durability: Canyon G5 components were developed by our pros on the world's toughest trails., Fork steer tube diameter: 1 1/8", Clamping diameter: 31,8 mm, Material: Aluminium (AL)
Handlebar
Canyon G5, G5 stands for gravity riding, and category 5. This aluminium bar has superb ergonomics and durability., Clamping diameter: 31,8 mm, Width: 780 mm, Rise: 30 mm
Grips
Canyon G5
Seat
Saddle
Ergon SM10 Enduro, Gender: Unisex, Weight: 245 g
Seatpost
Canyon G5, Clamp diameter: 30,9 mm, Material: Aluminium (AL)
Motor & Battery
Battery
SRAM Powerpack
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.418 mm | 1.353 mm | 1.302 mm | 1.256 mm |
| Front Center | 787 mm | 815 mm | 844 mm | 874 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 136 mm | 136 mm | 136 mm | 136 mm |
| Stack | 624 mm | 629 mm | 638 mm | 647 mm |
| Reach | 440 mm | 465 mm | 490 mm | 515 mm |
| Top Tube Length | 578 mm | 604 mm | 631 mm | 658 mm |
| Seat Tube Angle | 69.7 ° | 70.1 ° | 70.6 ° | 71 ° |
| Seat Tube Length | 395 mm | 430 mm | 445 mm | 460 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 100 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 435 mm | 435 mm | 435 mm | 435 mm |
| Wheelbase | 1220 mm | 1248 mm | 1277 mm | 1307 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 761 mm | 771 mm | 773 mm | 778 mm |
| Front Travel | 170 mm | 170 mm | 170 mm | 170 mm |
| Rear Travel | 175 mm | 175 mm | 175 mm | 175 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Max Height | 177 cm | 185 cm | 194 cm | cm |
