Canyon Torque Mullet AL 5 2024
2024 Mountain
Estimate price |
2,899$
Weight | 16.5 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 170mm -
Travel Rear 170mm -
Fork RockShox ZEB Select
-
Groupset Deore, Race Face -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
MD
172cm - 185cm
LG
180cm - 194cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Torque AL, Aluminium long-travel freeride frame built for seasons-long hard riding at the bike park and in the big mountains. Frame category 5., Axle dimension: 12x148 mm, Material: Aluminium (AL)
Suspension Fork
RockShox ZEB Select 29", Travel: 170 mm, Fork steer tube diameter: 1 1/8" - 1,5", Weight: 3.34 kg
Rear Shock
RockShox Super Deluxe Select+
Drivetrain
Rear Derailleur
Shimano Deore M6100, Cage length: long, Weight: 317 g
Shift Levers
Shimano DEORE M6100
Cassette
Shimano Deore M6100, Number of sprockets: 12
Crank
Race Face RIDE
Bottom Bracket
Race Face BSA, Bottom bracket standard: BSA 68/73
Chain
Shimano CN-M6100
Chain Guide
e*thirteen Ultra Compact Upper Slider
Pedals
None included
Wheels
Rims
RaceFace AR30 | Shimano MT400, Rotor mount: Center Lock, Weight: 1.19 kg | RaceFace AR30 | Shimano MT510 SH12, Rotor mount: Center Lock, Weight: 993 g
Tires
Maxxis Minion DHR II 3C MaxxTerra, Width: 2.4", Weight: 900 g | Maxxis Assegai 3C MaxxGrip, Width: 2,5", Weight: 1.16 kg
Brakes
Brakes
Shimano Deore M6120 | Shimano Deore
Cockpit
Stem
Canyon G5, Modern design, extreme durability: Canyon G5 components were developed by our pros on the world's toughest trails., Fork steer tube diameter: 1 1/8", Clamping diameter: 31,8 mm
Handlebar
Canyon G5, G5 stands for gravity riding, and category 5. This aluminium bar has superb ergonomics and durability., Clamping diameter: 31,8 mm, Width: 780 mm, Rise: 30 mm
Grips
Canyon G5
Seat
Saddle
Ergon SM10 Enduro, Developed on the Enduro World Series, the SM10 gives you max freedom of movement in technical terrain., On certain models, this saddle may be substituted for an alternate, equivalent Selle San Marco model., Potentially affected models include:, Spectral 6 27 (Model #3184), Spectral 6 29 (Model #3185)
Seatpost
Iridium Dropper, The Iridium dropper post offers 150-200mm of on-the-fly seat height adjustability., Clamp diameter: 30,9 mm, Material: Aluminium (AL), Weight: 600 g
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.423 mm | 1.365 mm | 1.313 mm | 1.267 mm |
| Front Center | 780 mm | 809 mm | 839 mm | 868 mm |
| Rake | 45 mm | 45 mm | 45 mm | 45 mm |
| Trail | 136 mm | 136 mm | 136 mm | 136 mm |
| Stack | 619 mm | 628 mm | 637 mm | 646 mm |
| Reach | 435 mm | 460 mm | 485 mm | 510 mm |
| Top Tube Length | 567 mm | 594 mm | 620 mm | 647 mm |
| Seat Tube Angle | 78 ° | 78 ° | 78 ° | 78 ° |
| Seat Tube Length | 395 mm | 430 mm | 435 mm | 475 mm |
| Head Tube Angle | 63.5 ° | 63.5 ° | 63.5 ° | 63.5 ° |
| Head Tube Length | 95 mm | 105 mm | 115 mm | 125 mm |
| Chainstay Length | 424 mm | 424 mm | 424 mm | 424 mm |
| Wheelbase | 1202 mm | 1231 mm | 1261 mm | 1290 mm |
| Bottom Bracket Drop | 30 mm | 30 mm | 30 mm | 30 mm |
| Standover Height | 758 mm | 763 mm | 768 mm | 775 mm |
| Front Travel | 170 mm | 170 mm | 170 mm | 170 mm |
| Rear Travel | 170 mm | 170 mm | 170 mm | 170 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Max Height | 177 cm | 185 cm | 194 cm | cm |
