Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 650b -
Groupset Alfine -
Suspension Rigid -
Drivetrain Belt Drive, IGH -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
169cm - 184cm
LG
182cm - 191cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Canyon Commuter Design, Material: Aluminium, Axle Dimension: 10 x 135 mm, Brake Mount: Post Mount
Suspension Fork
Canyon F31 CF Disc, Material: Carbon, Steerer: 1 1/4'' - 1 1/2'', Axle Dimension: 9 x 100 mm, Brake Mount: Post Mount
Drivetrain
Shift Levers
Shimano Alfine S700 11s
Cassette
Gates CDX 24T
Crank
Miranda Delta CDX 50T
Bottom Bracket
SRAM Pressfit GXP
Chain
Gates CDN Belt
Wheels
Rims
DT Swiss XR 331 | Shimano Alfine 11s, Rim Material: Aluminium, Inner Width: 20 mm, Hub Type: SG-S7001-11
Tires
Schwalbe Kojak 35 mm
Brakes
Brakes
Shimano MT500
Disk Rotors
Shimano RT54, Disc Mount: Centerlock
Cockpit
Stem
Canyon V18
Handlebar
Canyon H27 Flatbar AL, Material: Aluminium, Rise: 0 mm
Grips
Selle San Marco Canvas
Headset
Acros AiX-321
Seat
Saddle
Selle San Marco Regal Woven
Seatpost
Canyon S25 VCLS 2.0 CF, Material: Carbon, Setback: -2 mm / 10 mm, Technology: VCLS 2.0 | Fliphead, Weight: 235 g
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.444 mm | 1.42 mm | 1.418 mm | 1.397 mm |
| Stack | 556 mm | 585 mm | 604 mm | 623 mm |
| Reach | 385 mm | 412 mm | 426 mm | 446 mm |
| Top Tube Length | 566 mm | 585 mm | 605 mm | 653 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 400 mm | 455 mm | 495 mm | 535 mm |
| Head Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Head Tube Length | 136 mm | 165 mm | 185 mm | 230 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 998 mm | 1034 mm | 1054 mm | 1085 mm |
| Wheels | 650 | 650 | 650 | 650 |
| Rider Min Height | 158 cm | 169 cm | 182 cm | 189 cm |
| Rider Max Height | 171 cm | 184 cm | 191 cm | cm |
About this model
Urban 8.0 belongs to the Canyon Urban model. There are 3 bikes that carry this model name.
Safety
Your safety should be the top priority when you go for a ride. In short, make sure that you always use a helmet, high visibility clothing, and proper lights when riding at night-time.
Commuter bikes average price
If you want an acceptable Commuter bike you should know that the average price is 762$. However, even though the average price of a Commuter bike is lower, you might still be able to get a top-quality bike. To make sure you don’t pay a higher amount than normal for your bike, always do some components analysis and read reviews.
When Canyon released this model in 2018, its price was 1804$. Comparing this to the average Commuter bike price, we see that the price is 136.75% more expensive.
Overview of components
Fork material
Urban 8.0 has a carbon fork, so, its weight is considerably lighter than one made out of steel. However, they cost a bit more than steel forks.
Wheels size
When leaving the production line, the Urban 8.0 model has aluminum wheels. After 700c wheels, 650b is the second most popular choice for road bikes. However, if you want higher speeds, you should look for a bike with 700c wheels.
Brakes
For your safety, it is important to have quality breaks on your bike. Canyon Urban 8.0 has Hydraulic Disc brakes installed. These kinds of brakes are among the most popular models used on bikes. To sum up, you can ride your bike with confidence.
