Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset NX Eagle -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Accordo Tour, Material: Aluminium, 28", Steuerrohr: 1 1/8"-1.5", Ausfallende: 10x135mm, Bremsaufnahme: Postmount 160mm
Suspension Fork
CENTURION Trekking rigid, 1.5" tapered
Drivetrain
Rear Derailleur
SRAM NX Eagle, 1x12
Shift Levers
SRAM NX Eagle, SL NX MMX Eagle Trigger, Matchmaker
Cassette
SRAM GX Eagle, CS XG 1275 EAGLE, 10-50T
Crank
SRAM S-650 Eagle 38T incl. BG, Länge: 170mm (XS, S/M), 175mm (M/L)
Chain
SRAM CN NX Eagle
Pedals
VP VPE-461
Wheels
Front Hub
SHIMANO DH-UR700-3D / PROCRAFT Centerlock 12 light, hub dynamo, 6V, 3W, 9x100mm, 32H, XD, 10x135, 32H
Rear Hub
SHIMANO DH-UR700-3D / PROCRAFT Centerlock 12 light, hub dynamo, 6V, 3W, 9x100mm, 32H, XD, 10x135, 32H
Rims
PROCRAFT MD23, IW 23mm, tubeless ready
Spokes
PROCRAFT stainless 2.0
Tires
SCHWALBE Road Cruiser 47-622
Brakes
Brakes
SHIMANO Deore, BR-M6100, resin pad
Brake Levers
SHIMANO Deore, BL-M6100
Cockpit
Stem
PROCRAFT Comp II, Winkel: 17°, Länge: 60mm (XS), 70mm (S/M), 80mm (M/L)
Handlebar
PROCRAFT Riser Pro, Durchmesser: 31.8mm, Breite: 700mm, Rise: 22mm
Seat
Saddle
PROCRAFT Tour II
Seatpost
PROCRAFT Pro III, Durchmesser: 27.2mm, Länge: 350mm
Fit data
Geometry
