Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Carbon -
Travel Front 100mm -
Fork RockShox SID Select+
-
Groupset GX Eagle -
Suspension Hardtail -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Backfire Carbon PCF, Material: Carbon pcf fiber, 29", Steuerrohr: 1 1/8"-1.5", Ausfallende: 12x148mm, Bremsaufnahme: 160mm Postmount
Suspension Fork
ROCK SHOX SID Select+, Federweg: 100mm, 2-Pos Remote Lockout, 1.5" tapered, rake: 44mm
Drivetrain
Rear Derailleur
SRAM GX Eagle, 1x12
Shift Levers
SRAM GX Eagle, SL GX MMX Eagle Trigger, Matchmaker
Cassette
SRAM GX Eagle, CS XG 1275 EAGLE, 10-52T
Crank
SRAM GX Eagle 32T, narrow-wide, Länge: 170mm (XS), 175mm (S/M, M/L, XL)
Chain
SRAM NX Eagle
Wheels
Rims
DT SWISS XR1700 Spline, 15x110 12x148 IW 25mm tubeless ready
Tires
CONTINENTAL CrossKing 29x2.20", tubeless ready, black chilli, Protection
Brakes
Brakes
MAGURA MT4, performance pad
Brake Levers
MAGURA MT4
Cockpit
Stem
PRC ST2, Winkel: 6°, Länge: 70mm (XS), 80mm (S/M), 90mm (M/L), 100mm (XL)
Handlebar
PRC Top Flat Carbon, Durchmesser: 31.8mm, Breite: 740mm
Seat
Saddle
PROCRAFT Race III
Seatpost
PRC Carbon Race, Durchmesser: 30.9mm, Länge: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM/MD | MD/LG | XL |
|---|---|---|---|---|
| Stack | 602 mm | 606 mm | 630 mm | 653 mm |
| Top Tube Length | 574 mm | 599 mm | 622 mm | 644 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 69.3 ° | 69.3 ° | 69.3 ° | 69.3 ° |
| Head Tube Length | 90 mm | 95 mm | 120 mm | 145 mm |
| Chainstay Length | 430 mm | 430 mm | 435 mm | 440 mm |
| Wheelbase | 1079 mm | 1105 mm | 1135 mm | 1164 mm |
| Wheels | 29" | 29" | 29" | 29" |
