Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork Suntour XCT
-
Groupset Acera -
Suspension Hardtail -
Drivetrain 2 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Backfire Comp, Material: Aluminium, Steuerrohr: 1 1/8" straight, Ausfallende: 10x135mm, Bremsaufnahme: IS/Postmount
Suspension Fork
SR SUNTOUR XCT ATB, Federweg: 100mm, pre load adjuster, 1 1/8" straight
Drivetrain
Rear Derailleur
SHIMANO Acera, RD-M3020-8, 2x8
Front Derailleur
SHIMANO FD-M315 TS, Durchmesser: 34.9mm, top-swing
Shift Levers
SHIMANO SL-M315-2L / SHIMANO SL-M315-8R, mit Ganganzeige
Cassette
SHIMANO HG31, 11-34T
Crank
SHIMANO FC-M315-2 36-22T, Länge: 175mm (29"), 170mm (27.5")
Chain
KMC Z8.3
Pedals
VP VPE-899
Wheels
Front Hub
SHIMANO HB-TX506 / SHIMANO FH-TX506, 9x100mm, 32H, 10x135mm, 32H
Rear Hub
SHIMANO HB-TX506 / SHIMANO FH-TX506, 9x100mm, 32H, 10x135mm, 32H
Rims
PROCRAFT JD 200, IW 20mm
Spokes
PROCRAFT stainless 2.0
Tires
KENDA Small Block Eight 27.5/29x2.10"
Brakes
Brakes
TEKTRO HD-M275, organic pads
Brake Levers
TEKTRO HD-M275
Cockpit
Stem
PROCRAFT Comp II, Winkel: 7°, Länge: 60mm (XXS), 70mm (XS), 80mm (S), 90mm (M), 100mm (L)
Handlebar
PROCRAFT Riser Comp, Durchmesser: 31.8mm, Breite: 680mm (27.5"), 720mm (29"), Rise: 25mm
Seat
Saddle
PROCRAFT Sport
Seatpost
PROCRAFT Comp II, Durchmesser: 27.2mm, 27.5": Länge: 350mm, 29": Länge: 400mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM | SM | MD | LG |
|---|---|---|---|---|---|---|
| Stack | 590 mm | 609 mm | 627 mm | 628 mm | 646 mm | 665 mm |
| Top Tube Length | 559 mm | 582 mm | 600 mm | 600 mm | 618 mm | 635 mm |
| Seat Tube Angle | 73.5 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 330 mm | 380 mm | 430 mm | 430 mm | 480 mm | 530 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° | 69.5 ° | 69.5 ° | 69.5 ° |
| Head Tube Length | 90 mm | 110 mm | 130 mm | 90 mm | 110 mm | 130 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 440 mm | 440 mm | 440 mm |
| Wheelbase | 1066 mm | 1085 mm | 1104 mm | 1104 mm | 1123 mm | 1141 mm |
| Wheels | 27" | 27" | 27" | 29" | 29" | 29" |
