Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork Suntour MOBIE
-
Groupset CUES -
Suspension Hardtail -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH PowerTube 625Wh -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
156cm - 166cm
SM
163cm - 174cm
MD
171cm - 182cm
LG
179cm - 189cm
XL
185cm - 195cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Country R intube, Material: Aluminium, 27.5", Steuerrohr: 1.5" straight, Ausfallende: 12x148mm, Bremsaufnahme: Postmount 180mm, Rahmenkennung: UBP047A
Suspension Fork
SR SUNTOUR MOBIE34-AIR LOR, Federweg: 80mm, 1.5" tapered
Drivetrain
Rear Derailleur
SHIMANO CUES, RD-U6000, 1x11
Shift Levers
SHIMANO CUES, SL-U6000-11R, mit Ganganzeige
Cassette
SHIMANO CS-LG400-11, 11-50T
Crank
CENTURION R Comp Gen4, mattschwarz, Länge: 165mm, TCK10
Chain
SHIMANO CN-LG500, Linkglide
Chain Guide
CURANA FLY
Pedals
VP VPE-461
Wheels
Front Hub
SHIMANO HB-TC500-15 / SHIMANO FH-TC500-HM-B, 15x100mm, 32H, 12x148mm, 32H
Rear Hub
SHIMANO HB-TC500-15 / SHIMANO FH-TC500-HM-B, 15x100mm, 32H, 12x148mm, 32H
Rims
PROCRAFT MD23, IW 23mm, tubeless ready
Spokes
PROCRAFT stainless 2.0
Tires
SCHWALBE Smart Sam 27.5x2.25", Performance Line mit Reflex
Brakes
Brakes
TEKTRO HD-M535, organic pad
Brake Levers
TEKTRO HD-M535
Cockpit
Stem
PROCRAFT Adjustable Deluxe AICR, Winkel: 0-70°, Länge: 90mm
Handlebar
PROCRAFT Riser Pro, Durchmesser: 31.8mm, Breite: 700mm, Rise: 22mm
Seat
Saddle
PROCRAFT City II
Seatpost
PROCRAFT Drop-Suspension, Durchmesser: 30.9mm, Hub: 100mm (XS, S), 120mm (M, L, XL), Remote: SHIMANO SL-MT500-L
Motor & Battery
Motor
BOSCH Performance Line CX, max. 85 Nm, 250 W, Modi: Turbo / Sport / Tour / ECO, weitere Modi frei konfigurierbar
Battery
BOSCH PowerTube 625Wh
Charger
BOSCH Standard Charger, 4 Ampere
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack | 630 mm | 649 mm | 667 mm | 686 mm | 707 mm |
| Top Tube Length | 574 mm | 599 mm | 624 mm | 649 mm | 675 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° | 73.5 ° |
| Seat Tube Length | 380 mm | 430 mm | 480 mm | 530 mm | 580 mm |
| Head Tube Angle | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° | 68.5 ° |
| Head Tube Length | 160 mm | 180 mm | 200 mm | 220 mm | 240 mm |
| Chainstay Length | 445 mm | 445 mm | 445 mm | 445 mm | 445 mm |
| Wheelbase | 1105 mm | 1132 mm | 1159 mm | 1186 mm | 1214 mm |
| Wheels | 650 | 650 | 650 | 650 | 650 |
| Rider Min Height | 156 cm | 163 cm | 171 cm | 179 cm | 185 cm |
| Rider Max Height | 166 cm | 174 cm | 182 cm | 189 cm | 195 cm |
