Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 800 -
Suspension Rigid -
Drivetrain 2 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Crossfire Gravel, Material: Aluminium, 28", Steuerrohr: 1 1/8"-1.5", Ausfallende: 12x142mm, Bremsaufnahme: Flatmount 160mm
Suspension Fork
CENTURION CARBON road/gravel II, 1.5" tapered
Drivetrain
Rear Derailleur
SHIMANO GRX 820, RD-RX820, 2x12
Front Derailleur
SHIMANO GRX 820, FD-RX820-F, brazed on type
Shift Levers
SHIMANO GRX 820, ST-RX820-L, ST-RX820-R
Cassette
SHIMANO CS-HG710-12, 11-36T
Crank
SHIMANO GRX 820 48-31T, FC-RX820-12, Länge: 170mm (XXS, XS), 172.5mm (S/M), 175mm (M/L, XL, XXL)
Chain
SHIMANO CN-M7100-12
Wheels
Front Hub
DT SWISS 350 Road db CL, 12x100mm, 28H, 12x142mm, 28H
Rear Hub
DT SWISS 350 Road db CL, 12x100mm, 28H, 12x142mm, 28H
Rims
PROCRAFT Altitude GD30, IW 21mm, tubeless ready
Spokes
PROCRAFT stainless 2.0/1.8
Tires
WTB Nano 40-622, tubeless ready, TCS
Brakes
Brakes
SHIMANO GRX 820, BR-RX820, resin pad
Cockpit
Stem
PROCRAFT Road Race, Winkel: 7°, Länge: 60mm (XXS), 70mm (XS), 80mm (S/M), 90mm (M/L), 100mm (XL), 110mm (XXL)
Handlebar
PROCRAFT Gravel Pro II, Durchmesser: 31.8mm, Breite: 420mm (XXS, XS), 440mm (S/M, M/L, XL, XXL)
Seat
Saddle
PROCRAFT Race III
Seatpost
PROCRAFT Pro III, Durchmesser: 27.2mm, Länge: 350mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XXS | XS | SM/MD | MD/LG | XL | XXL |
|---|---|---|---|---|---|---|
| Stack | 549 mm | 569 mm | 589 mm | 609 mm | 629 mm | 649 mm |
| Top Tube Length | 531 mm | 544 mm | 558 mm | 572 mm | 585 mm | 599 mm |
| Seat Tube Angle | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° | 74 ° |
| Seat Tube Length | 470 mm | 500 mm | 530 mm | 560 mm | 590 mm | 620 mm |
| Head Tube Angle | 70 ° | 70.25 ° | 70.5 ° | 70.75 ° | 71 ° | 71.25 ° |
| Head Tube Length | 120 mm | 140 mm | 160 mm | 180 mm | 200 mm | 220 mm |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Wheelbase | 1023 mm | 1035 mm | 1048 mm | 1060 mm | 1072 mm | 1084 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
