Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 50mm -
Groupset CUES -
Suspension Hardtail -
Drivetrain 1 × 9 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
R' Bock 24 II, Material: Aluminium, 24", Steuerrohr: 1 1/8" straight, Ausfallende: 10x135mm, Bremsaufnahme: IS-mount
Suspension Fork
SF20 XCT-JR DS 24", Federweg: 50mm, 1 1/8" straight
Drivetrain
Rear Derailleur
SHIMANO CUES, RD-U4000, 1x9
Shift Levers
SHIMANO CUES, SL-U4000-9R, mit Ganganzeige
Cassette
SHIMANO CUES, CS-LG300-9, 11-46T
Crank
PROCARFT Kids Comp 28T incl. BG, Länge: 134mm
Chain
SHIMANO CN-LG500-9
Pedals
MARWI SP-202
Wheels
Front Hub
SHIMANO DH-3D32-QR / PROCRAFT 6-Bolt QR, hub dynamo, 6V 3W, 9x100mm, 32H, 10x135mm, 28H
Rear Hub
SHIMANO DH-3D32-QR / PROCRAFT 6-Bolt QR, hub dynamo, 6V 3W, 9x100mm, 32H, 10x135mm, 28H
Rims
PROCRAFT MPD19, IW 19mm
Spokes
PROCRAFT stainless 2.0
Tires
KENDA Small Block Eight 24x1.95", fold
Brakes
Brakes
TEKTRO Junior, HD-J285, organic pad
Brake Levers
TEKTRO Junior, HD-J285
Cockpit
Stem
PROCRAFT Kids, Winkel: 0°, Länge: 50mm
Handlebar
PROCRAFT Kids Pro, Durchmesser: 25.4mm, Breite: 520mm
Seat
Saddle
PROCRAFT Kids
Seatpost
PROCRAFT Pro III, Durchmesser: 27.2mm, Länge: 300mm
Fit data
Geometry
