Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 63mm -
Fork Suntour XCR Air
-
Groupset CUES -
Suspension Hardtail -
Drivetrain 1 × 10 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
R' Bock 24 II, Material: Aluminium, 24", Steuerrohr: 1 1/8" straight, Ausfallende: 10x135mm, Bremsaufnahme: IS-mount
Suspension Fork
SR SUNTOUR XCR-AIR LO DS, Federweg: 63mm, Lockout, 1 1/8" straight
Drivetrain
Rear Derailleur
SHIMANO CUES, RD-U6000-10, 1x10
Shift Levers
SHIMANO CUES, SL-U6000-10R, mit Ganganzeige
Cassette
SHIMANO CUES, CS-LG400-10, 11-48T
Crank
PROCRAFT Kids Pro 30T, narrow-wide, Länge: 140mm
Chain
SHIMANO CN-LG500
Pedals
MARWI SP-202
Wheels
Front Hub
PROCRAFT 6-Bolt QR, 9x100, 24H, 10x135mm, 28H
Rear Hub
PROCRAFT 6-Bolt QR, 9x100, 24H, 10x135mm, 28H
Rims
PROCRAFT MPD19, IW 19mm
Spokes
PROCRAFT stainless 2.0/1.8
Tires
SCHWALBE Rocket Ron 24x2.1", Performance Line, fold
Brakes
Brakes
TEKTRO Junior, HD-J285, organic pad
Brake Levers
TEKTRO Junior, HD-J285
Cockpit
Stem
PROCRAFT Kids, Winkel: 0°, Länge: 50mm
Handlebar
PROCRAFT Kids Pro, Durchmesser: 25.4mm, Breite: 520mm
Seat
Saddle
PROCRAFT Kids
Seatpost
PROCRAFT Race, Durchmesser: 27.2mm, Länge: 300mm
Fit data
Geometry
