Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Ultegra -
Suspension Rigid -
Drivetrain 2 × 11 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered P Fork
Drivetrain
Rear Derailleur
Shimano Ultegra,R8000 SS, 11 speed
Front Derailleur
Shimano Ultegra, R8000, 11 speed
Shift Levers
Microshift Bar-end, 11 speed
Cassette
Shimano Ultegra, 11-30, 11 Speed
Crank
Shimano Ultegra, R8000, 52/36T, 11 Speed
Bottom Bracket
FSA, BBright thread together, 24mm spindle
Chain
Shimano HG701, 11 speed
Wheels
Rims
Vision Team 35 Disc
Tires
Zaffiro Pro V G2.0 700x25c
Brakes
Brakes
Riderever Triva
Brake Levers
Riderever Trivia Carbon
Cockpit
Stem
Cervélo Alloy
Handlebar
Zipp Vuka Alumina Basebar and Extensions
Headset
FSA IS2 1-1/8 x 1-3/8
Seat
Saddle
Cervélo Tri Saddle
Seatpost
Cervélo SP23 Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.273 mm | 1.271 mm | 1.267 mm | 1.271 mm | 1.279 mm | 1.325 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm | 261 mm |
| Front Center | 582 mm | 583 mm | 602 mm | 622 mm | 640 mm | 654 mm |
| Rake | 52 mm | 43 mm | 43 mm | 43 mm | 43 mm | 43 mm |
| Trail | 62.4 mm | 62.4 mm | 62.4 mm | 62.4 mm | 62.4 mm | 62.4 mm |
| Stack | 485 mm | 506 mm | 522 mm | 540 mm | 559 mm | 587 mm |
| Reach | 381 mm | 398 mm | 412 mm | 425 mm | 437 mm | 443 mm |
| Top Tube Length | 511 mm | 533 mm | 551 mm | 570 mm | 587 mm | 600 mm |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° | 72.5 ° |
| Head Tube Length | 87.5 mm | 101 mm | 118 mm | 137 mm | 157 mm | 187 mm |
| Chainstay Length | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm | 405 mm |
| Wheelbase | 975 mm | 976 mm | 995 mm | 1015 mm | 1033 mm | 1047 mm |
| Bottom Bracket Drop | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm | 75 mm |
| Standover Height | 732 mm | 758 mm | 773 mm | 790 mm | 808 mm | 836 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
