Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Rival AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon fiber
Suspension Fork
Cervélo All-Carbon, Tapered Soloist Fork
Drivetrain
Rear Derailleur
SRAM Rival AXS, 12 speed
Front Derailleur
SRAM Rival AXS, 12 speed
Shift Levers
SRAM Rival AXS, 12 speed
Cassette
SRAM Rival, 10-36, 12 Speed
Crank
SRAM Rival, 48/35T, DUB
Bottom Bracket
SRAM DUB, T47 BBright
Chain
SRAM Rival, 12 speed
Wheels
Rims
Rear: Vision Team i23 Disc, 23mm IW, direct pull, 12x142mm, XDR freehub, centerlock, tubeless compatible Front: Vision Team i23 Disc, 23mm IW, direct pull, 12x100mm, centerlock, tubeless compatible
Tires
Corsa N.EXT TLR G2.0 700x29mm
Brakes
Brakes
SRAM Rival
Cockpit
Stem
Cervélo ST36 Alloy, w Cable Management
Handlebar
Cervélo Alloy, 31.8mm clamp
Headset
FSA IS2 1-1/4 x 1-1/2
Seat
Saddle
Cervélo Saddle
Seatpost
Cervélo SP27 Carbon
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 48cm | 51cm | 54cm | 56cm | 58cm | 61cm |
|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.353 mm | 1.377 mm | 1.41 mm | 1.441 mm | 1.471 mm | 1.5 mm |
| Bottom Bracket Height | 261 mm | 261 mm | 264 mm | 264 mm | 266 mm | 266 mm |
| Front Center | 574 mm | 576 mm | 578 mm | 595 mm | 611 mm | 628 mm |
| Rake | 57.5 mm | 51.5 mm | 45.5 mm | 45.5 mm | 45.5 mm | 45.5 mm |
| Trail | 57.3 mm | 57.3 mm | 57.3 mm | 57.3 mm | 57.3 mm | 57.3 mm |
| Stack | 491 mm | 515 mm | 540 mm | 565 mm | 590 mm | 615 mm |
| Reach | 363 mm | 374 mm | 383 mm | 392 mm | 401 mm | 410 mm |
| Top Tube Length | 516 mm | 532 mm | 548 mm | 565 mm | 581 mm | 598 mm |
| Seat Tube Angle | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Seat Tube Length | 480 mm | 510 mm | 540 mm | 560 mm | 580 mm | 610 mm |
| Head Tube Angle | 71 ° | 72 ° | 73 ° | 73 ° | 73 ° | 73 ° |
| Head Tube Length | 86 mm | 106 mm | 130 mm | 156 mm | 184 mm | 211 mm |
| Chainstay Length | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm | 410 mm |
| Wheelbase | 972 mm | 974 mm | 977 mm | 994 mm | 1011 mm | 1028 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 69 mm | 69 mm |
| Standover Height | 708 mm | 748 mm | 774 mm | 798 mm | 824 mm | 848 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 |
