Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork Suntour XCM
-
Groupset Altus, Shimano -
Suspension Hardtail -
Motor Shimano 250W 40Nm mid-drive -
Battery Shimano E8035. 36V, 14 Ah (504WH) Integrated Battery with ABUS Lock -
Drivetrain 1 × 8 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Lightweight and durable 6061 Aluminum. Tapered 1.5" 1 1/8" headtube
Suspension Fork
SR Suntour XCM 34, 100mm coil fork with preload adjuster
Drivetrain
Rear Derailleur
Shimano Altus 8 speed
Shift Levers
Shimano Rapidfire Plus 8 speed with optical gear display
Crank
Shimano E5010 36 teeth with alloy guard (Length: 165MM)
Chain
KMC 8 speed.
Pedals
Fiberglass reinforced folding Nylon pedal. (Size: 9/16)
Wheels
Rims
Front: WTB 29", 32 hole double wall rim, with Shimano MT400 thru axle hub (15mm), Rear: WTB 29", 32 hole double wall rim, with Shimano MT400 8-11 speed thru axle hub (15mm)
Tires
Goodyear Peak 29 x 2.25" puncture resistant with reflective sidewalls.
Brakes
Brakes
Shimano MT200 Hydraulic disc brakes with 180mm rotors front and rear
Cockpit
Stem
90 degree rotateable stem with +7 degree rise. (Size: 31.8mm)
Handlebar
Lightweight 6061 Aluminumwith 60mm rise to provide heads up, confident handling. (Size: 31.8)
Grips
Charge Comfort Ergo Soft Rubber Grip
Seat
Saddle
Ergonomic Charge Comfort Saddle. Width: 180 mm
Seatpost
Lightweight and durable 6061 Aluminum. 31.6 diameter x 350 length.
Motor & Battery
Motor
Shimano E5000 250W
Battery
Shimano E8035. 36V, 14 Ah (504WH) Integrated Battery with ABUS Lock
Charger
Shimano 2 Amp E6002 Smart Charger
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | LG |
|---|---|---|
| Stack Reach Ratio | 1.45 mm | 1.41 mm |
| Bottom Bracket Height | 318 mm | 318 mm |
| Front Center | 746 mm | 746 mm |
| Rake | 76 mm | 56 mm |
| Trail | 69 mm | 91 mm |
| Stack | 625 mm | 633 mm |
| Reach | 430 mm | 448 mm |
| Top Tube Length | 615 mm | 638 mm |
| Seat Tube Angle | 73.5 ° | 73.5 ° |
| Seat Tube Length | 432 mm | 483 mm |
| Head Tube Angle | 68 ° | 68 ° |
| Head Tube Length | 127 mm | 135 mm |
| Chainstay Length | 476 mm | 476 mm |
| Wheelbase | 1217 mm | 1217 mm |
| Bottom Bracket Drop | 56 mm | 56 mm |
| Wheels | 29" | 29" |
Model Overview
XC completes the Charge E Xc model. There is 1 e-bike that carries this model name.
Safety
When cycling always take safety very seriously. Wear a helmet, obey the traffic rules and wear hi-vis clothes. In short, take care of yourself so others can take care of you.
Average price for Crosscountry e-bikes
According to our calculations, the average cost of a Crosscountry e-bike that is reliable is 2453$. However, paying less money than this amount doesn’t mean that you couldn’t get a great Crosscountry e-bike. In short, before purchasing your ideal e-bike do some research about its components, and also check for reviews online.
Furthermore, this bike was made available in 2023 for 2699$. Comparing the average cost of a Crosscountry e-bike to this one, you will see that XC price is 10.03% more expensive.
Overview of components
Fork
The Suntour XCM is included from the factory. It has a travel distance of 100mm. Bike forks are perfect to absorb shocks and provide a great riding experience overall. In conclusion, always look for a fork with decent travel when you buy a bike.
Wheels size
As for the wheels, Charge XC 2023, has a 29″ aluminum model. These wheels are more forgiving when you go over roots, rocks, bumps, or other obstacles you encounter on your ride. However, the 29″ wheels will add a little more weight to the e-bike itself.
Brakes
For your safety, it is important to have quality breaks on your bike. Charge XC has Hydraulic Disc brakes installed. With Hydraulic Disc brakes, you’ll be able to stop on a dime, even in wet or icy conditions. To sum up, you can ride your bike with confidence.
