Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Steel -
Groupset X1, GX Eagle -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
S1
127cm - 142cm
S1
127cm - 142cm
S2
140cm - 158cm
S2
140cm - 158cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Rear Shock
Rock Shox Deluxe Select, 165 x 45mm
Drivetrain
Rear Derailleur
SRAM GX Eagle
Shift Levers
SRAM NX Eagle
Cassette
SRAM NX Eagle 10-50t
Crank
SRAM X1 Eagle DUB, 155mm, 30t
Bottom Bracket
73mm Threaded
Chain
SRAM NX Eagle
Wheels
Front Hub
Chromag R4
Rear Hub
Chromag R4
Rims
Chromag Ally
Tires
Maxxis Minion DHF/DHRII
Brakes
Brakes
SRAM Code RSC
Cockpit
Stem
Chromag HiFi BSX 31mm
Handlebar
Chromag Vanguard, 720mm, 31.8mm
Grips
Chromag Format
Headset
44-56 Semi Integrated
Seat
Saddle
Chromag Overture
Seatpost
Chromag Bassix
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | S1 | S1 | S2 | S2 |
|---|---|---|---|---|
| Stack Reach Ratio | 1.492 mm | 1.553 mm | 1.385 mm | 1.438 mm |
| Bottom Bracket Height | 322 mm | 310 mm | 345 mm | 333 mm |
| Front Center | 670 mm | 670 mm | 715 mm | 714 mm |
| Rake | 37 mm | 37 mm | 38 mm | 37 mm |
| Stack | 552 mm | 559 mm | 568 mm | 575 mm |
| Reach | 370 mm | 360 mm | 410 mm | 400 mm |
| Top Tube Length | 497 mm | 499 mm | 541 mm | 543 mm |
| Seat Tube Angle | 77 ° | 76 ° | 77 ° | 76 ° |
| Seat Tube Length | 305 mm | 305 mm | 305 mm | 305 mm |
| Head Tube Angle | 65 ° | 64 ° | 65 ° | 64 ° |
| Head Tube Length | 95 mm | 95 mm | 95 mm | 95 mm |
| Chainstay Length | 417 mm | 420 mm | 427 mm | 430 mm |
| Wheelbase | 1087 mm | 1090 mm | 1142 mm | 1144 mm |
| Bottom Bracket Drop | -4 mm | 8 mm | 3 mm | 15 mm |
| Standover Height | 619 mm | 607 mm | 642 mm | 630 mm |
| Wheels | 24" | 24" | 26" | 26" |
| Rider Min Height | 127 cm | 127 cm | 140 cm | 140 cm |
| Rider Max Height | 142 cm | 142 cm | 158 cm | 158 cm |
