Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Shimano Dura-Ace Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
Shimano Shadow RD-R9250 12v, Shimano Shadow RD-R9250 12v
Front Derailleur
Shimano Dura Ace FD-R9250, Shimano Dura Ace FD-R9250
Shift Levers
Drivetrain, Shimano Dura Ace R9270 Di2 Disc - 12v, Shimano Dura Ace R9270 Di2 Disc - 12v
Cassette
Option 1 (Default), 11-30T, Option 2, 11-34T, Option 1 (Default), 11-30T, Option 2, 11-34T
Crank
Option 1 (Default), 52-36T, Option 2, 50-34T, Option 1 (Default), 52-36T, Option 2, 50-34T
Bottom Bracket
T47 Shimano with Steel Bearings, T47 Shimano with Steel Bearings
Chain
Shimano CN-M9100 12V, Shimano CN-M9100 12V
Wheels
Front Hub
Enve WS SES 3.4 C, ENVE INNERDRIVE™ Premium Straight-Pull, Shimano Dura Ace C50, E-Thru Contact Hub, Fulcrum Wind 420 DB, Aluminum, Low flanges. Sealed bearing, Adjustable, Fulcrum Racing 600 DB, Aluminum, Aluminum flanges Sealed cartridge bearings, Enve WS SES 3.4 C, ENVE INNERDRIVE™ Premium Straight-Pull, Shimano Dura Ace C50, E-Thru Contact Hub, Fulcrum Wind 420 DB, Aluminum, Low flanges. Sealed bearing, Adjustable, Fulcrum Racing 600 DB, Aluminum, Aluminum flanges Sealed cartridge bearings
Rear Hub
Enve WS SES 3.4 C, ENVE INNERDRIVE™ Premium Straight-Pull, Shimano Dura Ace C50, E-Thru Contact Hub, Fulcrum Wind 420 DB, Aluminum, Low flanges. Sealed bearing, Adjustable, Fulcrum Racing 600 DB, Aluminum, Aluminum flanges Sealed cartridge bearings, Enve WS SES 3.4 C, ENVE INNERDRIVE™ Premium Straight-Pull, Shimano Dura Ace C50, E-Thru Contact Hub, Fulcrum Wind 420 DB, Aluminum, Low flanges. Sealed bearing, Adjustable, Fulcrum Racing 600 DB, Aluminum, Aluminum flanges Sealed cartridge bearings
Rims
Enve WS SES 3.4 C, Front: 39 mm - Rear: 43 mm, Shimano Dura Ace C50, 50 mm, Fulcrum Wind 420 DB, 42 mm, Fulcrum Racing 600 DB, 24 mm, Enve WS SES 3.4 C, Front: 39 mm - Rear: 43 mm, Shimano Dura Ace C50, 50 mm, Fulcrum Wind 420 DB, 42 mm, Fulcrum Racing 600 DB, 24 mm
Tires
Enve WS SES 3.4 C, Pirelli PZero Race TLR 700x32, Shimano Dura Ace C50, Pirelli PZero Race TLR 700x32, Fulcrum Wind 420 DB, Pirelli PZero Race TLR 700x32, Fulcrum Racing 600 DB, Pirelli PZero Race TLR 700x32, Enve WS SES 3.4 C, Pirelli PZero Race TLR 700x32, Shimano Dura Ace C50, Pirelli PZero Race TLR 700x32, Fulcrum Wind 420 DB, Pirelli PZero Race TLR 700x32, Fulcrum Racing 600 DB, Pirelli PZero Race TLR 700x32
Brakes
Brakes
Brakes, Shimano Dura Ace R9270, 160 mm Front / 140 mm Rear, RT-CL900 rotors, Shimano Dura Ace R9270, 160 mm Front / 140 mm Rear, RT-CL900 rotors
Brake Levers
Shimano DURA-ACE ST-R9270, Shimano DURA-ACE ST-R9270
Cockpit
Stem
CC01 integrated cockpit, CC01 integrated cockpit
Handlebar
Colnago CC.01 integrated Cockpit - regular geometry. Colnago CC.01 integrated Cockpit - regular geometry.
Headset
ID:35 OD:47 36°/45° CeramicSpeed SLT Treated Bearings, ID:35 OD:47 36°/45° CeramicSpeed SLT Treated Bearings
Seat
Saddle
Components, "Prologo" Prologo Dimension, "Selle Italia" Novus Mg, "Prologo" Prologo Dimension, "Selle Italia" Novus Mg
Seatpost
Carbon seatpost, 0.15 offset, "D-Shape" section, Carbon seatpost, 0.15 offset, "D-Shape" section
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 43cm | 46cm | 49cm | 52cm | 55cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.414 mm | 1.448 mm | 1.482 mm | 1.51 mm | 1.534 mm |
| Bottom Bracket Height | 260 mm | 260 mm | 262 mm | 264 mm | 264 mm |
| Stack | 523 mm | 543 mm | 563 mm | 583 mm | 603 mm |
| Reach | 370 mm | 375 mm | 380 mm | 386 mm | 393 mm |
| Top Tube Length | 506 mm | 521 mm | 537 mm | 554 mm | 572 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Head Tube Angle | 70.6 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 117 mm | 136 mm | 157 mm | 177 mm | 198 mm |
| Chainstay Length | 412 mm | 412 mm | 415 mm | 415 mm | 417 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 74 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
