Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Shimano Ultegra Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
Shimano Shadow RD-R8150, Shimano Shadow RD-R8150
Front Derailleur
Shimano FD-R8150, Shimano FD-R8150
Shift Levers
Drivetrain, Shimano Ultegra R8170 Di2 Disc - 12v, Shimano Ultegra R8170 Di2 Disc - 12v
Cassette
Option 1 (Default), 11-30T, Option 2, 11-34T, Option 1 (Default), 11-30T, Option 2, 11-34T
Crank
Option 1 (Default), 52-36T, Option 2, 50-34T, Option 1 (Default), 52-36T, Option 2, 50-34T
Bottom Bracket
T47 Shimano with Steel Bearings, T47 Shimano with Steel Bearings
Chain
Shimano CN-M8100 12V, Shimano CN-M8100 12V
Wheels
Front Hub
Fulcrum Wind 420 DB, Aluminum, Low flanges. Sealed bearing, Adjustable, Fulcrum Racing 600 DB, Aluminum, Aluminum flanges Sealed cartridge bearings, Fulcrum Wind 420 DB, Aluminum, Low flanges. Sealed bearing, Adjustable, Fulcrum Racing 600 DB, Aluminum, Aluminum flanges Sealed cartridge bearings
Rear Hub
Fulcrum Wind 420 DB, Aluminum, Low flanges. Sealed bearing, Adjustable, Fulcrum Racing 600 DB, Aluminum, Aluminum flanges Sealed cartridge bearings, Fulcrum Wind 420 DB, Aluminum, Low flanges. Sealed bearing, Adjustable, Fulcrum Racing 600 DB, Aluminum, Aluminum flanges Sealed cartridge bearings
Rims
Fulcrum Wind 420 DB, 42 mm, Fulcrum Racing 600 DB, 24 mm, Fulcrum Wind 420 DB, 42 mm, Fulcrum Racing 600 DB, 24 mm
Tires
Fulcrum Wind 420 DB, Pirelli PZero Race TLR 700x32, Fulcrum Racing 600 DB, Pirelli PZero Race TLR 700x32, Fulcrum Wind 420 DB, Pirelli PZero Race TLR 700x32, Fulcrum Racing 600 DB, Pirelli PZero Race TLR 700x32
Brakes
Brakes
Brakes, Shimano Ultegra R8170, 160 mm Front / 140 mm Rear, RT-CL900 rotors, Shimano Ultegra R8170, 160 mm Front / 140 mm Rear, RT-CL900 rotors
Brake Levers
Shimano ULTEGRA ST-R8170, Shimano ULTEGRA ST-R8170
Cockpit
Stem
CC01 integrated cockpit, CC01 integrated cockpit
Handlebar
Colnago CC.01 integrated Cockpit - regular geometry. Colnago CC.01 integrated Cockpit - regular geometry.
Headset
ID:35 OD:47 36°/45° CeramicSpeed SLT Treated Bearings, ID:35 OD:47 36°/45° CeramicSpeed SLT Treated Bearings
Seat
Saddle
Components, Option 1, Prologo Scratch M5 Tirox, Option 2, Selle Italia Novus Boost EVO TI316 Superflow, Option 1, Prologo Scratch M5 Tirox, Option 2, Selle Italia Novus Boost EVO TI316 Superflow
Seatpost
Carbon seatpost, 0.15 offset, "D-Shape" section, Carbon seatpost, 0.15 offset, "D-Shape" section
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 43cm | 46cm | 49cm | 52cm | 55cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.414 mm | 1.448 mm | 1.482 mm | 1.51 mm | 1.534 mm |
| Bottom Bracket Height | 260 mm | 260 mm | 262 mm | 264 mm | 264 mm |
| Stack | 523 mm | 543 mm | 563 mm | 583 mm | 603 mm |
| Reach | 370 mm | 375 mm | 380 mm | 386 mm | 393 mm |
| Top Tube Length | 506 mm | 521 mm | 537 mm | 554 mm | 572 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° |
| Head Tube Angle | 70.6 ° | 71 ° | 71.5 ° | 72 ° | 72.5 ° |
| Head Tube Length | 117 mm | 136 mm | 157 mm | 177 mm | 198 mm |
| Chainstay Length | 412 mm | 412 mm | 415 mm | 415 mm | 417 mm |
| Bottom Bracket Drop | 76 mm | 76 mm | 74 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
