Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 12 -
Brakes Shimano GRX 800 Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
Shimano GRX 1x: Shimano RD-RX822-SGS, Shimano GRX 1x: Shimano RD-RX822-SGS
Front Derailleur
(This groupset has a single chainring), (This groupset has a single chainring)
Shift Levers
Drivetrain, Shimano GRX 822 1x, Shimano GRX 822 1x
Cassette
Shimano GRX 1x: 10-51 12v, Shimano GRX 1x: 10-51 12v
Crank
Shimano GRX 1x: 42T, Shimano GRX 1x: 42T
Bottom Bracket
Shimano T47-86mm, Shimano T47-86mm
Chain
Shimano GRX: Shimano CN-M8100 12V, Shimano GRX: Shimano CN-M8100 12V
Wheels
Front Hub
Aluminium, Sealed Cartridge Bearings, Aluminium, Sealed Cartridge Bearings
Rear Hub
Aluminium, Sealed Cartridge Bearings, Aluminium, Sealed Cartridge Bearings
Rims
Front: 24 mm; Rear: 24 mm, Front: 24 mm; Rear: 24 mm
Tires
Pirelli Cinturato Gravel 40 TLR, Pirelli Cinturato Gravel 40 TLR
Brakes
Brakes
Brakes, Shimano RX-820, 160 mm Front / 160 mm Rear, RT-MT800-S rotors, Shimano RX-820, 160 mm Front / 160 mm Rear, RT-MT800-S rotors
Brake Levers
Shimano ST-RX820, Shimano ST-RX820
Cockpit
Stem
DEDA Gravel, Size 450 - 480, Length: 90 mm, Sizes 520- 570, Length: 100 mm, DEDA Gravel, Size 450 - 480, Length: 90 mm, Sizes 520- 570, Length: 100 mm
Handlebar
Deda Gravel 100, Sizes 46s, Width: 400 mm, Sizes 49s - 55s, Width: 420 mm, Sizes 58s, Width: 440 mm, Deda Gravel 100, Sizes 46s, Width: 400 mm, Sizes 49s - 55s, Width: 420 mm, Sizes 58s, Width: 440 mm
Seat
Saddle
Components, "Prologo" Kappa BK, "Selle Italia" Model X BB FEC, "Prologo" Kappa BK, "Selle Italia" Model X BB FEC
Seatpost
Carbon seatpost, 0.15 offset, "D-Shape" section, Carbon seatpost, 0.15 offset, "D-Shape" section
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 48cm | 52cm | 54cm | 57cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.442 mm | 1.458 mm | 1.469 mm | 1.478 mm | 1.463 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 266 mm | 266 mm | 266 mm |
| Stack | 535 mm | 554 mm | 573 mm | 591 mm | 600 mm |
| Reach | 371 mm | 380 mm | 390 mm | 400 mm | 410 mm |
| Top Tube Length | 524 mm | 539 mm | 560 mm | 581 mm | 596 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
