Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset RED XPLR eTap -
Suspension Rigid -
Drivetrain 1 × 12 Electronic -
Brakes SRAM RED Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
SRAM RED XPLR eTap AXS - RD-RED-E-D1, SRAM RED XPLR eTap AXS - RD-RED-E-D1
Front Derailleur
This goupset has a single chainring, This goupset has a single chainring
Shift Levers
Drivetrain, SRAM RED XPLR D1 eTAP AXS, SRAM RED XPLR D1 eTAP AXS
Cassette
10-44T 12s, 10-44T 12s
Crank
40T, 40T
Bottom Bracket
T47 SRAM DUB Road, T47 SRAM DUB Road
Chain
RED Chain - CN-RED-D1 12s, RED Chain - CN-RED-D1 12s
Wheels
Front Hub
Hubs with direct pull spokes, Hubs with direct pull spokes
Rear Hub
Hubs with direct pull spokes, Hubs with direct pull spokes
Rims
45mm, 45mm
Tires
Pirelli Cinturato Gravel 40 TLR, Pirelli Cinturato Gravel 40 TLR
Brakes
Brakes
Brakes, Disc brakes SRAM Red eTap AXS HRD SHIFT-BRAKE SYSTEM - CenterLine XR Rotor, Disc brakes SRAM Red eTap AXS HRD SHIFT-BRAKE SYSTEM - CenterLine XR Rotor
Brake Levers
SRAM Red eTap AXS HRD SHIFT-BRAKE SYSTEM, SRAM Red eTap AXS HRD SHIFT-BRAKE SYSTEM
Cockpit
Stem
Integrated cockpit (CC.01 Wide), Size 450 - 480, Length: 90 mm, Sizes 520- 570, Length: 100 mm, Integrated cockpit (CC.01 Wide), Size 450 - 480, Length: 90 mm, Sizes 520- 570, Length: 100 mm
Handlebar
CC.01 Wide integrated cockpit, Sizes 450, Width: 400 mm, Sizes 480 -540, Width: 420 mm, Sizes 570, Width: 440 mm, CC.01 Wide integrated cockpit, Sizes 450, Width: 400 mm, Sizes 480 -540, Width: 420 mm, Sizes 570, Width: 440 mm
Seat
Saddle
Components, "Prologo" Kappa BK, "Selle Italia" Model X BB FEC, "Prologo" Kappa BK, "Selle Italia" Model X BB FEC
Seatpost
Carbon seatpost, 0.15 offset, "D-Shape" section, Carbon seatpost, 0.15 offset, "D-Shape" section
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 45cm | 48cm | 52cm | 54cm | 57cm |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.442 mm | 1.458 mm | 1.469 mm | 1.478 mm | 1.463 mm |
| Bottom Bracket Height | 264 mm | 264 mm | 266 mm | 266 mm | 266 mm |
| Stack | 535 mm | 554 mm | 573 mm | 591 mm | 600 mm |
| Reach | 371 mm | 380 mm | 390 mm | 400 mm | 410 mm |
| Top Tube Length | 524 mm | 539 mm | 560 mm | 581 mm | 596 mm |
| Seat Tube Angle | 74 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Head Tube Angle | 71 ° | 71.5 ° | 71.5 ° | 71.5 ° | 71.5 ° |
| Chainstay Length | 430 mm | 430 mm | 430 mm | 430 mm | 430 mm |
| Bottom Bracket Drop | 72 mm | 72 mm | 70 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
