Colnago M10 Frameset 2012
2012 Road
Estimate price |
4,499$
Weight | 0.93 kg
Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Frame Carbon -
Wheels 700c -
Suspension Rigid
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Monocoque Carbon
Suspension Fork
ColnagoM10 Carbon
Drivetrain
Front Derailleur
Braze-On Required
Bottom Bracket
68mm / English
Cockpit
Headset
Colnago Integrated C-HS1
Seat
Seatpost
31.6mm Required
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42s | 45s | 48s | 50s | 52s | 54s | 56s | 58s |
|---|---|---|---|---|---|---|---|---|
| Top Tube Length | 513 mm | 522 mm | 533 mm | 543 mm | 553 mm | 568 mm | 583 mm | 593 mm |
| Seat Tube Angle | 75.49 ° | 75.14 ° | 74.58 ° | 74 ° | 73.57 ° | 72.83 ° | 72.75 ° | 72.75 ° |
| Seat Tube Length | 420 mm | 450 mm | 480 mm | 500 mm | 520 mm | 540 mm | 560 mm | 580 mm |
| Head Tube Length | 120 mm | 123 mm | 125 mm | 143 mm | 161 mm | 177 mm | 185 mm | 202 mm |
| Chainstay Length | 400 mm | 402 mm | 405 mm | 408 mm | 410 mm | 412 mm | 415 mm | 416 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
About this model
M10 Frameset completes the Colnago M10 model. There are 2 frames that carry this model name.
Safety
Make sure you wear a helmet on every ride, and that your bike performs well. In short, this means checking the tires, brakes, and chain to make sure everything is in good working order.
Endurance frames average price
Our math shows that the average cost of a dependable Endurance frame is 1905$. However, you could also get a good Endurance frame even if you pay a lower amount than the average price. As a general rule of thumb, you should always read reviews about the frame and its components before buying it to ensure you don’t pay too much.
This frame was released in 2012 and its price was 4499$. Comparing the average cost of an Endurance frame to this one, you will see that M10 Frameset price is 136.17% higher.
Average weight for Endurance frames
If we make a quick analysis of the average weight of an Endurance frame, we get 1.64 kg (3.62 lbs). A lighter bike will give you some extra advantage when climbing. A heavier bike will have more speed for descents.
Weighing 0.93 kg (2.05 lbs), the M10 Frameset model is much lighter than average. To sum up, it’s 76.34% lighter than the average weight of Endurance frames.
M10 Frameset components
Fork material
The fork on this frame is made out of carbon, so, it’s a great addition to the frame’s value. However, carbon forks should be regularly inspected for damage because even the smallest crack could cause the fork to fall apart.
