Bike details
Overview
Key information split into simple groups.
Frame summary
-
-
Suspension Rigid -
Brakes Mechanical Disc
Sizing
Recommended size guide.
SM
158cm - 170cm
MD
168cm - 179cm
LG
176cm - 187cm
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Bottom Bracket
BSA 68mm, BSA 68mm
Wheels
Tires
28 mm with 4 mm clearance, 28 mm with 4 mm clearance
Brakes
Brakes
Flat Mount disc (rear), Post Mount (front), Flat Mount disc (rear), Post Mount (front)
Cockpit
Handlebar
Colnago TT1 handlebars + Stem cover included, Aerobars not included, Colnago TT1 handlebars + Stem cover included, Aerobars not included
Headset
Bearings 19x30x6,5; 36x45° - included, Bearings 19x30x6,5; 36x45° - included
Seat
Seatpost
Seatpost, Special superlight seatpost, fixed setback (32mm from leading edge) made in collaboration with Darimo. ISO compliant, Seatpost weight, 145g, Seatpost compatibility, Compatibile with standard and prologo monorail saddle. Seatpost, Special superlight seatpost, fixed setback (32mm from leading edge) made in collaboration with Darimo. ISO compliant, Seatpost weight, 145g, Seatpost compatibility, Compatibile with standard and prologo monorail saddle.
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.19 mm | 1.207 mm | 1.151 mm |
| Bottom Bracket Height | 264 mm | 266 mm | 266 mm |
| Stack | 471.7 mm | 490.7 mm | 490.7 mm |
| Reach | 396.5 mm | 406.5 mm | 426.5 mm |
| Seat Tube Angle | 77 ° | 77 ° | 77 ° |
| Head Tube Angle | 72 ° | 72 ° | 72 ° |
| Chainstay Length | 400 mm | 400 mm | 400 mm |
| Bottom Bracket Drop | 72 mm | 70 mm | 70 mm |
| Wheels | 700 | 700 | 700 |
| Rider Min Height | 158 cm | 168 cm | 176 cm |
| Rider Max Height | 170 cm | 179 cm | 187 cm |
