Colnago V4Rs Disc Red AXS w/Fulcrum Racing Wind 400 Wheels 2024
2024 Road
Estimate price |
12,419$
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset RED AXS -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Carbon
Suspension Fork
Carbon
Drivetrain
Rear Derailleur
SRAM Red AXS
Front Derailleur
SRAM Red AXS
Shift Levers
SRAM Red AXS
Cassette
SRAM Red 12-speed
Crank
SRAM Red
Chain
SRAM Red 12-speed
Pedals
Not Included
Wheels
Rims
Fulcrum Wind 400
Brakes
Brakes
SRAM Red AXS Hydraulic Disc
Cockpit
Stem
Colnago CC.01 Integrated Bar and Stem
Handlebar
Colnago CC.01 Integrated Bar and Stem
Headset
Integrated
Seat
Seatpost
Colnago V4Rs
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 45.5cm | 48.5cm | 51cm | 53cm | 55cm | 57cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.378 mm | 1.392 mm | 1.407 mm | 1.436 mm | 1.456 mm | 1.471 mm | 1.493 mm |
| Stack | 510 mm | 522 mm | 539 mm | 557 mm | 575 mm | 593 mm | 612 mm |
| Reach | 370 mm | 375 mm | 383 mm | 388 mm | 395 mm | 403 mm | 410 mm |
| Top Tube Length | 504 mm | 517 mm | 535 mm | 550 mm | 567 mm | 586 mm | 599 mm |
| Seat Tube Angle | 75.5 ° | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° | 73 ° |
| Seat Tube Length | 420 mm | 455 mm | 485 mm | 510 mm | 530 mm | 550 mm | 570 mm |
| Head Tube Angle | 70.6 ° | 71 ° | 71.5 ° | 71.8 ° | 72.5 ° | 72.9 ° | 73.1 ° |
| Head Tube Length | 103 mm | 114 mm | 130 mm | 148 mm | 164 mm | 181 mm | 200 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
