Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset Super Record, Super Record Wireless -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Campagnolo Super Record Mechanical Disc
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
Cambio Campagnolo Super Record WRL12v - RD23-SR12WRL, Cambio Campagnolo Super Record WRL12v - RD23-SR12WRL
Front Derailleur
Campagnolo Super Record WRL - FD23-SR12WRL, Campagnolo Super Record WRL - FD23-SR12WRL
Shift Levers
Drivetrain, Campagnolo Super Record WRL (Wireless) DB 12, Campagnolo Super Record WRL (Wireless) DB 12
Cassette
Option 1 (Default), 10-27T, Option 2, 10-29T, Option 1 (Default), 10-27T, Option 2, 10-29T
Crank
Option 1 (Default), 48-32T, Option 2, 45-29T, Option 1 (Default), 48-32T, Option 2, 45-29T
Bottom Bracket
BSA (English Threaded Bottom Bracket) Campagnolo, BSA (English Threaded Bottom Bracket) Campagnolo
Chain
Super Record WRL 12S, Super Record WRL 12S
Wheels
Front Hub
Carbon Hubs, CULT™ ceramic bearings, Integrated flanges, Carbon Hubs, CULT™ ceramic bearings, Integrated flanges
Rear Hub
Carbon Hubs, CULT™ ceramic bearings, Integrated flanges, Carbon Hubs, CULT™ ceramic bearings, Integrated flanges
Rims
45 mm, 45 mm
Tires
Enve WS SES 3.4 C, Pirelli PZero Race TLR 700x28, Shimano Dura Ace C50, Pirelli PZero Race 700x28, Fulcrum Wind 420 DB, Pirelli PZero Race 700x28, Fulcrum Racing 600 DB, Pirelli P7 Sport 700x28, Enve WS SES 3.4 C, Pirelli PZero Race TLR 700x28, Shimano Dura Ace C50, Pirelli PZero Race 700x28, Fulcrum Wind 420 DB, Pirelli PZero Race 700x28, Fulcrum Racing 600 DB, Pirelli P7 Sport 700x28
Brakes
Brakes
Brakes, Campagnolo Super Record WRL - Standard Flat Mount, Campagnolo Super Record WRL - Standard Flat Mount
Brake Levers
Campagnolo Ergopower DB Super Record WRL 12V, Campagnolo Ergopower DB Super Record WRL 12V
Cockpit
Stem
CC01 integrated cockpit, CC01 integrated cockpit
Handlebar
Colnago CC.01 integrated Cockpit - regular geometry. Colnago CC.01 integrated Cockpit - regular geometry.
Headset
1"1/8 and 1"1/4 - SLT Treated Bearings, 1"1/8 and 1"1/4 - SLT Treated Bearings
Seat
Saddle
Components, Scratch M5 Nack 140 Hard Black, Selle Italia SLR Boost Superflow Carbon Rail, (subject to stock availability), Scratch M5 Nack 140 Hard Black, Selle Italia SLR Boost Superflow Carbon Rail, (subject to stock availability)
Seatpost
Standard Option, Carbon seatpost, 15mm offset, Sold separately, Carbon seatpost, 0 mm offset, Standard Option, Carbon seatpost, 15mm offset, Sold separately, Carbon seatpost, 0 mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 45.5cm | 48.5cm | 51cm | 53cm | 55cm | 57cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.372 mm | 1.387 mm | 1.404 mm | 1.428 mm | 1.448 mm | 1.468 mm | 1.489 mm |
| Bottom Bracket Height | 262 mm | 262 mm | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Stack | 509 mm | 523 mm | 539 mm | 557 mm | 575 mm | 593 mm | 612 mm |
| Reach | 371 mm | 377 mm | 384 mm | 390 mm | 397 mm | 404 mm | 411 mm |
| Top Tube Length | 503 mm | 514 mm | 530 mm | 544 mm | 564 mm | 578 mm | 595 mm |
| Seat Tube Angle | 75.5 ° | 75.3 ° | 74.8 ° | 74.5 ° | 73.8 ° | 73.5 ° | 73 ° |
| Head Tube Angle | 70.6 ° | 71.5 ° | 72.3 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 101 mm | 112 mm | 127 mm | 146 mm | 162 mm | 181 mm | 199 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
