Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Groupset Ultegra Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Shimano Ultegra Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Drivetrain
Rear Derailleur
Shimano Shadow RD-R8150, Shimano Shadow RD-R8150
Front Derailleur
Shimano FD-R8150, Shimano FD-R8150
Shift Levers
Drivetrain, Shimano Ultegra R8170 Di2 Disc - 12v, Shimano Ultegra R8170 Di2 Disc - 12v
Cassette
Option 1 (Default), 11-30T, Option 2, 11-34T, Option 1 (Default), 11-30T, Option 2, 11-34T
Crank
Option 1 (Default), 52-36T, Option 2, 50-34T, Option 1 (Default), 52-36T, Option 2, 50-34T
Bottom Bracket
BSA (English Threaded Bottom Bracket) Shimano, BSA (English Threaded Bottom Bracket) Shimano
Chain
Shimano CN-M8100 12V, Shimano CN-M8100 12V
Wheels
Front Hub
Fulcrum Wind 420 DB, Aluminum, Low flanges. Sealed bearing, Adjustable, Fulcrum Racing 600 DB, Aluminum, Aluminum flanges Sealed cartridge bearings, Fulcrum Wind 420 DB, Aluminum, Low flanges. Sealed bearing, Adjustable, Fulcrum Racing 600 DB, Aluminum, Aluminum flanges Sealed cartridge bearings
Rear Hub
Fulcrum Wind 420 DB, Aluminum, Low flanges. Sealed bearing, Adjustable, Fulcrum Racing 600 DB, Aluminum, Aluminum flanges Sealed cartridge bearings, Fulcrum Wind 420 DB, Aluminum, Low flanges. Sealed bearing, Adjustable, Fulcrum Racing 600 DB, Aluminum, Aluminum flanges Sealed cartridge bearings
Rims
Fulcrum Wind 420 DB, 42 mm, Fulcrum Racing 600 DB, 24 mm, Fulcrum Wind 420 DB, 42 mm, Fulcrum Racing 600 DB, 24 mm
Tires
Fulcrum Wind 420 DB, Pirelli PZero Race 700x28, Fulcrum Racing 600 DB, Pirelli P7 Sport 700x28, Fulcrum Wind 420 DB, Pirelli PZero Race 700x28, Fulcrum Racing 600 DB, Pirelli P7 Sport 700x28
Brakes
Brakes
Brakes, Shimano Ultegra R8170, 160 mm Front / 140 mm Rear, RT-CL900 rotors, Shimano Ultegra R8170, 160 mm Front / 140 mm Rear, RT-CL900 rotors
Brake Levers
Shimano ULTEGRA ST-R8170, Shimano ULTEGRA ST-R8170
Cockpit
Stem
CC01 integrated cockpit, CC01 integrated cockpit
Handlebar
Colnago CC.01 integrated Cockpit - regular geometry. Colnago CC.01 integrated Cockpit - regular geometry.
Headset
1"1/8 and 1"1/4 - SLT Treated Bearings, 1"1/8 and 1"1/4 - SLT Treated Bearings
Seat
Saddle
Components, Prologo Scratch M5 Tirox, Selle Italia Novus Boost EVO TI316 Superflow, (subject to stock availability), Prologo Scratch M5 Tirox, Selle Italia Novus Boost EVO TI316 Superflow, (subject to stock availability)
Seatpost
Standard Option, Carbon seatpost, 15mm offset, Sold separately, Carbon seatpost, 0 mm offset, Standard Option, Carbon seatpost, 15mm offset, Sold separately, Carbon seatpost, 0 mm offset
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | 42cm | 45.5cm | 48.5cm | 51cm | 53cm | 55cm | 57cm |
|---|---|---|---|---|---|---|---|
| Stack Reach Ratio | 1.372 mm | 1.387 mm | 1.404 mm | 1.428 mm | 1.448 mm | 1.468 mm | 1.489 mm |
| Bottom Bracket Height | 262 mm | 262 mm | 264 mm | 264 mm | 264 mm | 264 mm | 264 mm |
| Stack | 509 mm | 523 mm | 539 mm | 557 mm | 575 mm | 593 mm | 612 mm |
| Reach | 371 mm | 377 mm | 384 mm | 390 mm | 397 mm | 404 mm | 411 mm |
| Top Tube Length | 503 mm | 514 mm | 530 mm | 544 mm | 564 mm | 578 mm | 595 mm |
| Seat Tube Angle | 75.5 ° | 75.3 ° | 74.8 ° | 74.5 ° | 73.8 ° | 73.5 ° | 73 ° |
| Head Tube Angle | 70.6 ° | 71.5 ° | 72.3 ° | 72.5 ° | 73 ° | 73 ° | 73.5 ° |
| Head Tube Length | 101 mm | 112 mm | 127 mm | 146 mm | 162 mm | 181 mm | 199 mm |
| Chainstay Length | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm | 408 mm |
| Bottom Bracket Drop | 74 mm | 74 mm | 72 mm | 72 mm | 72 mm | 72 mm | 72 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 | 700 | 700 |
