Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 100mm -
Fork RockShox Pike DJ
-
Suspension Hardtail -
Drivetrain Single Speed -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
155cm - 170cm
MD
165cm - 185cm
LG
180cm - 200cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
ABSOLUT, 26", Alloy 6061, triple butted (T4, T6), with adjustable horizontal dropouts
Suspension Fork
ROCKSHOX Pike DJ, 100 mm travel, 26", Solor Air, rebound, LSC, 15 x 100 mm, 40mm offset, 0 Token
Drivetrain
Cassette
SPANK 11t
Crank
BMX 3-pcs, 170 mm, Crmo, 19 mm spindle, Chainring: 28t, Alloy 6061
Bottom Bracket
BSA 73 mm
Chain
KMC K1 WIDE, 1/2" x 1/8", super light
Wheels
Front Hub
Rear: SPANK Single Speed DJ - Front: SPANK Hex J-Type, Rear: 32h, 4 sealed bearings, 10 x 135 mm, female axle, black - Front: 32h, 2 sealed bearings, 15 x 100 mm, black
Rear Hub
Rear: SPANK Single Speed DJ - Front: SPANK Hex J-Type, Rear: 32h, 4 sealed bearings, 10 x 135 mm, female axle, black - Front: 32h, 2 sealed bearings, 15 x 100 mm, black
Rims
SPANK Spike Race 33, 26", 32h, 28 mm inner width, tubeless ready
Tires
Rear: SCHWALBE Billy Bonkers - Front: SCHWALBE Billy Bonkers, Rear: 26" x 2.1", Performance Line, Addix - Front: 26" x 2.1", Performance Line, Addix
Brakes
Brakes
SRAM Guide T, 4 pistons, hydraulic disc brake, Rotors: SRAM HS2 160 mm, 6-bolt
Cockpit
Stem
TITLE ST1, 35 mm extension, 31.8 mm
Handlebar
TITLE AH1, 31.8 mm, 800 mm width, 38 mm rise, Alloy AL-7050 T74
Grips
ODI Elite Motion, Soft pro compound, single clamp, black
Headset
ACROS ZS44 / ZS56, Alloy cups, sealed bearings
Seat
Saddle
COMMENCAL, Soft padding, steel rails
Seatpost
RIDE ALPHA, 31,6 mm, 250 mm length
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG |
|---|---|---|---|
| Stack Reach Ratio | 1.433 mm | 1.364 mm | 1.286 mm |
| Bottom Bracket Height | 318 mm | 318 mm | 318 mm |
| Front Center | 648 mm | 668 mm | 693 mm |
| Rake | 42 mm | 42 mm | 42 mm |
| Trail | 87 mm | 87 mm | 87 mm |
| Stack | 566 mm | 566 mm | 566 mm |
| Reach | 395 mm | 415 mm | 440 mm |
| Top Tube Length | 577 mm | 597 mm | 622 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 310 mm | 310 mm | 310 mm |
| Head Tube Angle | 69 ° | 69 ° | 69 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm |
| Chainstay Length | 390 mm | 390 mm | 390 mm |
| Wheelbase | 1037 mm | 1057 mm | 1082 mm |
| Bottom Bracket Drop | 25 mm | 25 mm | 25 mm |
| Standover Height | 672 mm | 672 mm | 672 mm |
| Wheels | 26" | 26" | 26" |
| Rider Min Height | 155 cm | 165 cm | 180 cm |
| Rider Max Height | 170 cm | 185 cm | 200 cm |
