condor Pista Frameset 2024

2024 Urban

Estimate price | 1,803$

Open compare Use advisor

Bike details

Overview

Key information split into simple groups.

Frame summary

Category
- Urban
- |
- Hipster
Frame Steel

Sizing

Recommended size guide.

46cm
150cm - 160cm
52cm
169cm - 175cm
55cm
176cm - 185cm
58cm
186cm - 193cm
61cm
194cm - 200cm

Parts list

Components

Main components, grouped by system.

Bike components

Frame

Frame

Columbus Spirit, triple-butted steel,1800g

Suspension Fork

Condor RC Carbon, 380g

Fit data

Geometry

Numbers for sizing and ride feel.

Size	46cm	49cm	52cm	55cm	58cm	61cm
Stack Reach Ratio	1.345 mm	1.404 mm	1.391 mm	1.468 mm	1.545 mm	1.621 mm
Bottom Bracket Height	270 mm	270 mm	270 mm	270 mm	270 mm	270 mm
Rake	45 mm	45 mm	45 mm	45 mm	45 mm	45 mm
Stack	507 mm	518 mm	534 mm	568 mm	598 mm	624 mm
Reach	377 mm	369 mm	384 mm	387 mm	387 mm	385 mm
Top Tube Length	513 mm	518 mm	537 mm	555 mm	570 mm	580 mm
Seat Tube Angle	75 °	74 °	74 °	73.5 °	73 °	72.5 °
Seat Tube Length	420 mm	450 mm	480 mm	510 mm	540 mm	570 mm
Head Tube Angle	71 °	71.5 °	72 °	73.5 °	74 °	74 °
Head Tube Length	110 mm	120 mm	135 mm	165 mm	195 mm	222 mm
Chainstay Length	405 mm	405 mm	405 mm	405 mm	408 mm	410 mm
Bottom Bracket Drop	70 mm	70 mm	70 mm	70 mm	70 mm	70 mm
Wheels	700	700	700	700	700	700
Rider Min Height	150 cm	cm	169 cm	176 cm	186 cm	194 cm
Rider Max Height	160 cm	cm	175 cm	185 cm	193 cm	200 cm
