Conway MS 4.9 Hardtail 2024
2024 Mountain
Estimate price |
755$
Weight | 14.8 kg
Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Wheels 29" -
Travel Front 100mm -
Fork RST GILA
-
Groupset Acera, Altus -
Suspension Hardtail -
Drivetrain 3 × 8 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
SM
158cm - 171cm
MD
168cm - 180cm
LG
178cm - 189cm
XL
186cm - 199cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CONWAY, Alu
Suspension Fork
RST "Gila ML", 100 mm
Drivetrain
Rear Derailleur
SHIMANO "Acera RD-360", 8speed
Front Derailleur
SHIMANO "Altus FD-M313"
Shift Levers
SHIMANO "SL-M315"
Cassette
SHIMANO "CS-HG31", 11-34 Z.
Crank
SHIMANO "FC-TY301", 24/34/42 Z. 170 mm
Bottom Bracket
SHIMANO "BB-UN100"
Pedals
Welgo "C280DU" 1-piece
Wheels
Front Hub
CONWAY "Alloy" QR
Rear Hub
CONWAY "Alloy" QR
Rims
CONWAY Hohlkammer
Spokes
Stahl schwarz
Tires
WTB "Ranger", 57-622
Brakes
Brakes
TEKTRO "HD-M280"
Brake Levers
TEKTRO "HD-M280"
Cockpit
Stem
CONWAY, 31,8, 70 mm
Handlebar
CONWAY Riser, Ø 31,8, 720 mm
Grips
CONWAY "Sport"
Headset
ZS44 / ZS56, Reduzierkonus
Seat
Saddle
SELLE ROYAL "Vivo Athletic Ergo", He
Seatpost
CONWAY Patent, 31,6 mm, 300 mm
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL |
|---|---|---|---|---|
| Stack Reach Ratio | 1.718 mm | 1.63 mm | 1.55 mm | 1.541 mm |
| Stack | 634 mm | 634 mm | 634 mm | 652 mm |
| Reach | 369 mm | 389 mm | 409 mm | 423 mm |
| Top Tube Length | 570 mm | 590 mm | 610 mm | 630 mm |
| Seat Tube Angle | 72 ° | 72 ° | 72 ° | 72 ° |
| Seat Tube Length | 406 mm | 457 mm | 508 mm | 559 mm |
| Head Tube Angle | 70 ° | 70 ° | 70 ° | 70 ° |
| Head Tube Length | 120 mm | 120 mm | 120 mm | 140 mm |
| Chainstay Length | 448 mm | 448 mm | 448 mm | 448 mm |
| Wheelbase | 771 mm | 800 mm | 829 mm | 865 mm |
| Wheels | 29" | 29" | 29" | 29" |
| Rider Min Height | 158 cm | 168 cm | 178 cm | 186 cm |
| Rider Max Height | 171 cm | 180 cm | 189 cm | 199 cm |
