Conway Xyron S 5.9 Full Suspension 2024
2024 E-bike
Estimate price |
6,881$
Weight | 26.9 kg E-bike
Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Wheels 29" -
Travel Front 150mm -
Travel Rear 150mm -
Fork Fox Performance Float 36
-
Groupset XT -
Suspension Full -
Motor Bosch 250W 85Nm mid-drive -
Battery BOSCH "Powertube 750", Lithium-Ionen mit BMS, 750 Wh -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CONWAY Fully Intube Bosch, Alu
Suspension Fork
FOX "Performance 36 Float", 150 mm
Rear Shock
FOX "Float X" 150 mm
Drivetrain
Rear Derailleur
SHIMANO "Deore XT RD-M8100 Shadow Plus", 12speed
Shift Levers
SHIMANO "Deore XT SL-M8100"
Cassette
SHIMANO "CS-M7100", 10-51 Z.
Crank
MIRANDA "Epsilon", 165 mm
Bottom Bracket
BOSCH
Wheels
Front Hub
MAVIC "E-Deemax 30", 15 x 110 mm
Rear Hub
MAVIC "E-Deemax 30", 12 x 148 mm
Rims
MAVIC "E-Deemax 30"
Spokes
MAVIC
Tires
SCHWALBE "Magic Mary", Soft, 62-622
Brakes
Brakes
SHIMANO „Deore XT BR-M8120", 4-Kolben
Brake Levers
SHIMANO "Deore XT BL-M8100"
Cockpit
Stem
LEVEL 9 "A-Head 35", 31,8 mm
Handlebar
LEVEL 9 "Low Riser", Ø 31,8, 780 mm
Grips
SQLAB "70X"
Headset
ZS56 / ZS56, Blocklock
Seat
Saddle
FIZIK "Aidon"
Seatpost
CONTEC "Drop - A - Gogo", 31,6 mm, 100 mm
Motor & Battery
Motor
BOSCH Mittelmotor Gen.4 "Performance CX", 36 V, 250 W
Battery
BOSCH "Powertube 750", Lithium-Ionen mit BMS, 750 Wh
Remote
BOSCH "BRC3300"
Charger
Bosch 4 Ah
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | SM | MD | LG | XL | XXL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.5 mm | 1.432 mm | 1.399 mm | 1.368 mm | 1.339 mm |
| Stack | 633 mm | 633 mm | 642 mm | 651 mm | 660 mm |
| Reach | 422 mm | 442 mm | 459 mm | 476 mm | 493 mm |
| Top Tube Length | 585 mm | 605 mm | 625 mm | 645 mm | 665 mm |
| Seat Tube Angle | 76 ° | 76 ° | 76 ° | 76 ° | 76 ° |
| Seat Tube Length | 400 mm | 430 mm | 460 mm | 490 mm | 520 mm |
| Head Tube Angle | 65 ° | 65 ° | 65 ° | 65 ° | 65 ° |
| Head Tube Length | 120 mm | 120 mm | 130 mm | 140 mm | 150 mm |
| Chainstay Length | 465 mm | 465 mm | 465 mm | 465 mm | 465 mm |
| Wheels | 29" | 29" | 29" | 29" | 29" |
