Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Groupset GRX 800, GRX 600 -
Suspension Rigid -
Drivetrain 1 × 11 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 161cm
SM
159cm - 169cm
MD
166cm - 177cm
LG
174cm - 184cm
XL
181cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Co-op Cycles 6061 aluminum
Suspension Fork
Carbon with 1-1/8 to 1-1/2 tapered steerer tube
Drivetrain
Rear Derailleur
Shimano GRX RD-RX812, Shadow Plus Design
Front Derailleur
N/A
Shift Levers
Shimano GRX ST-810 with integrated dropper lever
Cassette
Shimano SLX, 11-42T, 11-speed
Crank
Shimano GRX 600, 40T
Bottom Bracket
Shimano GRX
Chain
Shimano HG701 11-speed?
Pedals
Not included
Wheels
Front Hub
Shimano RS470 for 12 mm thru axle
Rear Hub
Shimano RS470 for 12 mm thru axle
Rims
WTB ST i23, TCS, including WTB TCS rim tape (tubeless ready)
Tires
WTB Nano 700c x 40 mm, aramid bead (tubeless ready)
Brakes
Brakes
Shimano GRX ST-RX810 hydraulic Hydraulic Disc Brake
Brake Levers
Shimano GRX BR-810
Cockpit
Stem
Co-op Cycles 6061 aluminum
Handlebar
Co-op Cycles Alloy, 12-degree flare
Headset
Integrated 1-1/8 x 1-1/2 in. tapered
Seat
Saddle
WTB Silverado Comp
Seatpost
X-Fusion Manic Gravel dropper post
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.397 mm | 1.4 mm | 1.435 mm | 1.449 mm | 1.465 mm |
| Rake | 55 mm | 55 mm | 50 mm | 50 mm | 50 mm |
| Stack | 521 mm | 532 mm | 554 mm | 571 mm | 592 mm |
| Reach | 373 mm | 380 mm | 386 mm | 394 mm | 404 mm |
| Top Tube Length | 513 mm | 528 mm | 545 mm | 563 mm | 585 mm |
| Seat Tube Angle | 75 ° | 74.5 ° | 74 ° | 73.5 ° | 73 ° |
| Seat Tube Length | 385 mm | 435 mm | 470 mm | 510 mm | 545 mm |
| Head Tube Angle | 70 ° | 70.5 ° | 71.5 ° | 71.5 ° | 72 ° |
| Chainstay Length | 432 mm | 432 mm | 432 mm | 432 mm | 432 mm |
| Wheelbase | 1022 mm | 1029 mm | 1029 mm | 1040 mm | 1045 mm |
| Standover Height | 698 mm | 727 mm | 756 mm | 785 mm | 811 mm |
| Wheels | 700 | 700 | 700 | 700 | 700 |
| Rider Min Height | 152 cm | 159 cm | 166 cm | 174 cm | 181 cm |
| Rider Max Height | 161 cm | 169 cm | 177 cm | 184 cm | 190 cm |
