Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork RockShox 35 Gold RL
-
Groupset SLX -
Suspension Full -
Drivetrain 1 × 12 -
Brakes Hydraulic Disc
Sizing
Recommended size guide.
XS
152cm - 161cm
SM
159cm - 169cm
MD
166cm - 177cm
LG
174cm - 184cm
XL
181cm - 190cm
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
6061 aluminum
Suspension Fork
RockShox 35 Gold RL, 140 millimeters
Rear Shock
RockShox Deluxe Select Plus RT
Drivetrain
Rear Derailleur
Shimano SLX Shadow 12-speed
Shift Levers
Shimano SLX Rapidfire Plus 12-speed
Cassette
Shimano Deore 12-speed 10-51T
Crank
Shimano SLX
Bottom Bracket
Shimano BB-MT801
Chain
KMC X12
Pedals
Not included
Wheels
Front Hub
Alloy with thru axle; 15 x 110 mm
Rear Hub
Alloy with thru axle; 12 x 148 mm
Rims
Co-op aluminum double-wall tubeless-ready
Tires
Maxxis Recon 60 TPI tubeless-ready
Brakes
Brakes
Shimano Deore hydraulic with resin pads Hydraulic Disc Brake
Brake Levers
Shimano Deore
Cockpit
Stem
Forged aluminum 4-bolt
Handlebar
Co-op Riser, 15 mm rise, 9-degree sweep
Headset
FSA Orbit 1-1/8 to 1-1/2 in.
Seat
Saddle
Co-op Steel Rail
Seatpost
X Fusion Manic dropper with remote
Fit data
Geometry
Numbers for sizing and ride feel.
| Size | XS | SM | MD | LG | XL |
|---|---|---|---|---|---|
| Stack Reach Ratio | 1.46 mm | 1.374 mm | 1.357 mm | 1.324 mm | 1.294 mm |
| Rake | 37 mm | 37 mm | 44 mm | 44 mm | 44 mm |
| Stack | 584 mm | 584 mm | 610.5 mm | 628.7 mm | 647 mm |
| Reach | 400 mm | 425 mm | 450 mm | 475 mm | 500 mm |
| Top Tube Length | 528.5 mm | 553.5 mm | 586.9 mm | 617.6 mm | 648.4 mm |
| Seat Tube Angle | 77.6 ° | 77.6 ° | 77.4 ° | 77.2 ° | 77.1 ° |
| Seat Tube Length | 360 mm | 379.5 mm | 394.5 mm | 409.5 mm | 449.5 mm |
| Head Tube Angle | 66 ° | 66 ° | 66 ° | 66 ° | 66 ° |
| Chainstay Length | 433 mm | 433 mm | 441 mm | 441 mm | 441 mm |
| Wheelbase | 1125 mm | 1150 mm | 1196 mm | 1229 mm | 1262 mm |
| Standover Height | 749 mm | 752 mm | 786 mm | 796 mm | 804 mm |
| Wheels | 27" | 27" | 29" | 29" | 29" |
| Rider Min Height | 152 cm | 159 cm | 166 cm | 174 cm | 181 cm |
| Rider Max Height | 161 cm | 169 cm | 177 cm | 184 cm | 190 cm |
