Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Carbon -
Groupset Dura-Ace Di2 -
Suspension Rigid -
Drivetrain 2 × 12 Electronic -
Brakes Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
CCT EVO Carbon
Suspension Fork
Corratec Road Pro Carbon Fork Disc
Drivetrain
Rear Derailleur
Shimano DURA-ACE Di2 RD-R9250 12s , Pulley: CeramicSpeed OSPW for Shimano DURA-ACE RD-R9250
Front Derailleur
Shimano Dura Ace Di2 FD-R 9250
Shift Levers
Shimano Dura-Ace ST-R9270 Dual Control with Servo-Wave
Cassette
Shimano DURA-ACE CS-R9200 12S: 11-34T
Crank
Look Carbon Crank 170/172.5/175mm , Powermeter SRM Origin Road Carbon PM9 (ANT 6 BT LE Technology), Chainrings: Carbon Ti EVO 50/34T (Alu/Carbon)
Bottom Bracket
custom-made Ceramic Speed T47a
Chain
UFO Factory Optimized Shimano 12S chain
Wheels
Rims
Obermayer EVO Schwarz ED SH 11 EXP full carbon , Tubeless, CeramicSpeed hubs, rims 24mm wide - 1230g (set)
Tires
Continental Grand Prix 5000S TR 28-622 black foldable
Brakes
Brakes
Shimano DURA ACE BR-R9270
Cockpit
Stem
corratec Carbon AERO length: , 90 / 100 / 110 mm / 120 mm, angle 12,5°
Handlebar
corratec Carbon bars AERO: , 380 / 400 / 420 mm wide
Seat
Saddle
Selle Italia SLR BOOST TEKNO Superflow Carbon
Seatpost
corratec Carbon AERO: , 300 / 370 mm long, 10mm offset
