Bike details
Overview
Key information split into simple groups.
Bike summary
-
Category -
Frame Aluminum -
Travel Front 100mm -
Fork RockShox Recon Silver RL
-
Groupset CUES -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Battery Power Tube 800 Horizontal -
Drivetrain 1 × 11 -
Brakes Tektro Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec EP MTC 100 27.5“ 100mm Rear Wheel Travel Aluminium 12x148mm
Suspension Fork
ROCK SHOX RECON SILVER RL 27,5“ 15x110mm 100mm
Rear Shock
ROCK SHOX DELUXE SELECT 170X35
Drivetrain
Rear Derailleur
SHIMANO RD-U6000 CUES GS 11-SPEED
Shift Levers
SHIMANO SL-U6000-11R CUES 11-SPEED
Cassette
SHIMANO CS-LG400-11 CUES 11-SPEED 11-50T
Crank
MIRANDA DM CF3D 38T w/guard
Chain
SHIMANO CN-LG500 LINKGLIDE 9/10/11 SPEED
Wheels
Rims
584-27 15x110 Center Lock front , 584-27 12x148 Center Lock rear
Tires
SCHWALBE JOHNNY WATTS 60-584 front , SCHWALBE JOHNNY WATTS 60-584 rear
Brakes
Brakes
TEKTRO HD M535 4/4 Piston203mm front , TEKTRO HD M535 4/4 Piston 180mm rear
Cockpit
Stem
ALLOY 0-90 Deg ADJUSTABLE 31.8 75/90mm ICR SP Connect
Handlebar
ALLOY 31.8 720mm 9 Deg Backsweep
Seat
Saddle
SELLE ROYAL ESSENZA Lady
Seatpost
KINDSHOCK RAGEi 30.9 100/125mm WESTY REMOTE
Motor & Battery
Motor
Bosch Performance Line CX Smart System
Battery
Power Tube 800 Horizontal
