Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 140mm -
Fork RockShox Psylo
-
Groupset CUES -
Suspension Full -
Motor Bosch 600W 85Nm mid-drive -
Battery BOSCH PowerPack Frame 600 EU , Energy: 625 wh -
Drivetrain 1 × 10 -
Brakes Tektro Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec EP MTC 120 29“ 120mm Rear Wheel Travel Aluminium 12x148mm
Suspension Fork
ROCK SHOX PSYLO SILVER RC 29“ 15x110mm 140mm
Rear Shock
ROCK SHOX SELECT 190x40
Drivetrain
Rear Derailleur
SHIMANO RD-U6000 CUES GS 10-SPEED
Shift Levers
SHIMANO SL-U6000-10R CUES 10-SPEED
Cassette
SHIMANO CS-LG300-10 CUES 10-SPEED 11-48T
Crank
MIRANDA DM CF3D 38T w/guard
Chain
SHIMANO CN-LG500 LINKGLIDE 9/10/11 SPEED
Wheels
Rims
622-30 15x110 Center Lock front , 622-30 12x148 Center Lock rear
Tires
SCHWALBE JOHNNY WATTS 60-622 front , SCHWALBE JOHNNY WATTS 60-622 rear
Brakes
Brakes
TEKTRO HD M535 4/4 Piston203mm front , TEKTRO HD M535 4/4 Piston 180mm rear
Cockpit
Stem
ALLOY 31.8 50mm 0 Deg
Handlebar
ALLOY 35.0 760mm 20mm Rise 9 Deg Backsweep
Seat
Saddle
SELLE ROYAL ESSENZA Gent
Seatpost
KINDSHOCK RAGEi 30.9 125/150mm WESTY REMOTE
Motor & Battery
Motor
Bosch Performance Line CX Smart System
Battery
BOSCH PowerPack Frame 600 EU , Energy: 625 wh
