Bike details
Overview
Key information split into simple groups.
Bike summary
-
-
Frame Aluminum -
Travel Front 80mm -
Fork Suntour NX 1
-
Groupset Gates -
Suspension Hardtail -
Motor Bosch 600W 85Nm mid-drive -
Battery Power Tube 800 Horizontal -
Drivetrain Belt Drive, Internally Geared Hub -
Brakes Tektro Gemini Hydraulic Disc
Parts list
Components
Main components, grouped by system.
Bike components
Frame
Frame
Corratec EP Trekking 28 CX Belt Gent Aluminium 10x135mm
Suspension Fork
SR SUNTOUR NX1 AIR LO DS 29“ 15x110mm 80mm
Drivetrain
Shift Levers
ENVIOLO MANUAL CONTROLLER TWIST PURE
Cassette
GATES 22T
Crank
Gates 46T
Chain
GATES carbon drive belt 122T
Wheels
Rims
622-27 15x110 front , 622-27 10x135mm 6-Bolt rear
Tires
SCHWALBE ENERGIZER ACTIVE PLUS 55-622 front , SCHWALBE ENERGIZER ACTIVE PLUS 55-622 rear
Brakes
Brakes
TEKTRO HD-M535 4 Piston 180mm front , TEKTRO HD-M535 4 Piston 180mm rear
Cockpit
Stem
ALLOY 0-90 Deg ADJUSTABLE 31.8 90/105mm ICR SP Connect
Handlebar
ALLOY 31.8mm 660mm 29 Deg Backsweep
Seat
Saddle
SELLE ROYAL ESSENZA Gent
Seatpost
SUSPENSION ALLOY 30.9x350mm
Motor & Battery
Motor
Bosch Performance Line CX Smart System
Battery
Power Tube 800 Horizontal
